Sharp PN-E521, PN-E601 manual 17 E

Page 17

Initialization (Reset)/Functional Restriction Setting (FUNCTION)

You can return the settings to their factory-preset values and restrict operations.

1.After pressing SIZE for about 5 seconds, press , , , and in that order.

FUNCTION

1/1









ALL RESET











OFF



ADJUSTMENT LOCK



RS-232C

UNLOCKED



OSD DISPLAY

ON



LED

ON



TEMPERATURE ALERT

LED



STATUS ALERT

OFF



POWER BUTTON

MONITOR



CONTROLLER INPUT









END[MENU]

2. Select and set the items.

ALL RESET

Resets the settings to the factory default settings.

Press , select ALL RESET, and then press MENU .

After initialization, turn the main power switch off and then back on.

When the PN-ZB01 (optional) is attached, press , select the resetting method, and then press MENU .

ALL RESET1.....Resets all the settings to the factory

default settings.

ALL RESET2.....Returns all settings to the factory default

settings except for the following items: LAN SETUP, RS-232C/LAN SELECT, ID No. SET, BAUD RATE, NETWORK, MAIL, SERVICE & SUPPORT, and SNMP (See page 11, and pages 33 to 36.)

ADJUSTMENT LOCK

You can disable operations on the monitor and the remote control unit that use buttons.

OFF....Enables operation.

1.........Disables all operations other than turning power

on/off and FUNCTION.

2.........Only the FUNCTION operation is enabled.

Disables all operations other than FUNCTION (not even power on/off).

RS-232C

(RS-232C/LAN when the PN-ZB01 (optional) is attached)

Specifies whether to allow control via RS-232C or LAN (see pages 18 and 29).

OSD DISPLAY

Hides/shows menus.

The FUNCTION screen cannot be hidden.

LED

Specifies whether to light the power LED.

OFF cannot be selected when STANDBY MODE is LOW POWER.

TEMPERATURE ALERT

Selects the notification method for an abnormal

temperature.



OFF

Do not notify about an abnormal



temperature.

OSD & LED...

When an abnormal temperature is



detected, the power LED flashes in red



and green alternately and the screen



displays a message: TEMPERATURE.

LED

When an abnormal temperature is



detected, the power LED flashes in red



and green alternately.

STATUS ALERT

Selects the notification method for a hardware error.

OFF

Do not notify about the error.

OSD & LED...

When a hardware error is detected, the



power LED flashes in red and the screen



displays a message: STATUS [xxxx].

LED

When a hardware error is detected, the



power LED flashes in red.

POWER BUTTON

Normally, leave this setting as MONITOR.

When using an optional part, if instruction appears, change the setting accordingly.

CONTROLLER INPUT

Normally, you do not need to change this setting. When using an optional part, if instruction appears, change the setting accordingly.

3. Press MENU to return to the normal screen.

TIPS

When both abnormal temperature and hardware error are detected, the hardware error notification overrides.

17 E

Image 17
