UNPACKING YOUR AMPLIFIER

PACKAGE CONTENTS

Please remove the amplifier and accessories from the carton. You should have the following:

(1) TA1501C Amplifier

(1) AC Power Cord

(4) Amplifier Feet

(1) Y Adapter Cable (Color may vary from the image shown here)

(1) Operating Manual

CONTACT INFORMATION IF PARTS ARE MISSING

If you are missing any items, please contact Clark Synthesis at 1-800-898-1945.

We recommend that you save the original carton to use if you ever have to ship the amplifier.

!WARNING: Before you set up this amplifier, make sure you read and observe the Important Safety Instructions in this manual.

6

TA1501C Amplifier

www.clarksynthesis.com
