Boss Audio Systems specifications Specifications, Model CAP30 CAP18 CAP8

Page 10

Specifications





30 Farad

18 Farad

8 Farad





Super Hybrid

Super Hybrid

Power





Power Capacitor

Power Capacitor

Capacitor

MODEL



CAP30

CAP18

CAP8

Capacitance, microfarads

30,000,000

18,000,000

8,000,000





Working voltage

16VDC

16VDC

16VDC

Surge voltage



20VDC

20VDC

20VDC

ESR (Equivalent series resistance)



0.00.015 Ohm @ 120Hz/25ºC









Capacitance tolerance





+/- 10%



















































All specifications subject to











change without notice.

Size:





















CAP 30



CAP18





CAP8

W:

7-3/4"

9-1/4"





6-1/4"





L:

11-1/2"

11"





9-3/4"





H:

3-1/2"

3-1/4"





2-3/4"





CAP8 • CAP18 • CAP30 User’s Manual - page 10
