PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it has been preassembled. Extra parts may be included.

M5 Washer

M8 Washer

M10

Split

16mm Wave

M8 Locknut

(132)–2

(102)–4



(97)–8

Washer

(105)–8

Washer (54)–2



M4 x 16mm

M6 x 12mm Button

M8 x 13mm

M8 x 38mm

Screw (101)–16

Screw (103)–8

Button Screw (82)–8

Button Bolt (96)–4



M10 x 25mm

M10 x 122mm

Button Screw

Button Screw (104)–4

(131)–4



5

Image 5
