Installation, Transit packing, Levelling

If despite all this your washer-dryer is still not running properly, call your local Authorized Service Centre providing the following information:

-fault

-model code (Mod. ....) and serial number (S/N ....)

shown on the data plate at the back of your washer.

Never use the services of an unauthorised servicing technician and insist on the use of original spare parts.

Installation

Transit packing

After removing the packing, check the appliance for damage. If you have any doubts do not use the washer and call a qualified technician. Keep the packaging components (plastic bags, polyester foam, nails etc.) out of the reach of children since they could be dangerous. The interior of the washer-dryer, has an oscillating unit which is fixed on the back by 3 screws during transport (figure 3). Before starting up the washer-dryer, release the unit, by unscrewing the 3 screws. Seal the screw holes with the plastic plugs supplied with the appliance.

hose having the white end fittings should be connected be- tween the cold supply and the threaded connection adjacent to the letter C on the rear of the machine (see fig. 5). Remem- ber to insert a sealing washer at each connection to ensure watertight joints. Do not overtighten the connections by using tools -hand tight is sufficient to prevent leaks. It is gener- ally more convenient to have these supplies away from the sink taps. Where no suitable hot water supply is available or it does not meet these requirements, both inlet hoses may be connected to a cold supply by using two taps etc., or a «T» junction on the plumbing (see fig. 6) however, use of cold water only will increase programme times.

Note: the maximum temperature should not exceed 70°C (158°F).

Fig. 3

Fig. 4

Levelling

The washer-dryer must be perfectly levelled. To level the appliance, only the front feet need to be adjusted (see fig. 4); remember that the inclination of the working surface must not be more than 2 degrees. If the washer-dryer is installed on a carpeted floor, check that there is sufficient ventilation space between the floor and the bottom of the washer-dryer.

Water supply

Both hot and cold water supplies are preferable and they should be between 34.5kN/m²(5lb/in²) and 1034.2kN/m² (150lb/in²) pressure. The hose having the red end fitting should be en- countered between the hot supply and the threaded connec- tion adjacent to the letter H on the rear of the machine. The

Fig. 5

Fig. 6

Drain hose

The drain hose (hooked pipe) is secured to the rear of the machine by support clips and may be routed to right or left as required (see fig. 7). The drain hose should be placed in a stand pipe with a minimum internal diameter of 38 mm (1½ inches) or it can be positioned over a sink (see fig. 8) or it can be connected as shown in fig. 9. The height of stand pipe or sink should be between 60 and 100 cm (24 and 40 inches). Care must be taken that the hose is not obstructed, twisted, submerged or kinked. If the hose is connected with an airtight joining, provision should be made to prevent syphoning.

WDG1195WG/1, WDG1195WG specifications

The Indesit WDG1195WG and WDG1195WG/1 wash and dry appliances stand out as versatile and efficient solutions for modern households. These models are designed to simplify laundry routines by combining washing and drying capabilities in one compact unit.

One of the main features of the Indesit WDG1195WG series is its impressive capacity. With the ability to handle up to 7 kg for washing and 5 kg for drying, it accommodates the needs of small to medium-sized families. This capacity ensures that users can complete laundry tasks efficiently, minimizing the time spent on chores.

In terms of technology, the Indesit WDG1195WG is equipped with intelligent sensors that optimize drying times based on the load size. This feature not only helps to achieve the best drying results but also contributes to energy efficiency, as it reduces unnecessary energy consumption. The energy rating for these models is notably efficient, making them an eco-friendly choice for environmentally-conscious consumers.

The appliance includes several washing programs tailored to various fabric types and laundry needs. Users can select from a range of settings, including programs for cotton, synthetic, and delicate fabrics. This versatility allows for custom-tailored care for garments, ensuring that items are treated appropriately for their specific requirements.

The WDG1195WG series also features a fast wash option, which allows users to clean lightly soiled items in a hurry, reducing wash times significantly. This is particularly beneficial for busy households that require quick turnaround for essential clothing.

Another characteristic that enhances usability is the intuitive control panel. Featuring easy-to-read icons and a straightforward layout, this user-friendly design enables individuals to set the preferred program and options without hassle. Furthermore, the delay start function allows users to program their laundry cycle to begin at a later time, accommodating various schedules.

Despite its robust features, the Indesit WDG1195WG remains compact, making it a suitable choice for apartments or homes where space is limited. Its sleek design fits seamlessly into any laundry space, combining functionality with aesthetics.

Overall, the Indesit WDG1195WG and WDG1195WG/1 are exemplary models in the realm of wash and dry appliances, offering convenience, efficiency, and practicality for everyday laundry needs. With their dependable performance and thoughtful features, these models are poised to become a staple in households seeking to streamline their laundry processes.
