Care and Maintenance,  Cleaning the Exterior

CARE AND MAINTENANCE

•Wipe the dryer surfaces, including the control panel, with a soft cloth and non-abrasive household detergents.

•Use a soft cloth to dry the surfaces.

•Do not pour water on the dryer.

Cleaning the Filters

Cleaning the Lint Filter:
a) Removing the Lint Filters:	ALL FILTERS MUST BE IN PLACE WHEN DRYING
Remove by pulling outward using the four	FILTERS MUST BE CLEANED BEFORE AND
(4) grip holes in the filter assembly.	FILTERS MUST BE CLEANED BEFORE AND
	AFTER EACH USE.

b)The filter assembly consists of three (3) parts

(See illustration)

c)Separate each of the above parts and clean the individual pieces using a SOFT brush or vacuum cleaner. DO NOT damage the filters

d)Re-install the filter assembly Reassemble the filter assembly in order Exhaust Filter – Lint Filter – Exhaust Shroud

Align the entire assembly with the recessed position in the back of the drum and press firmly until the entire assembly is secure.

a)Removing the Air Intake Filter:

Remove by pulling outward holding the filter housing by the top and bottom.

b)Remove the filter inside the housing and clean using a SOFT brush or vacuum cleaner.

c)Replace the filter housing by pushing upwards with your thumb until the latch is secure.
