APPLICATIONS

USING THE RDI-8 AS A DI BOX (DIRECT INJECTION UNIT)

Connect the signal you would like to convert from unbalanced to balanced to the RDI-8 via a 1/4” unbalanced plug to one of the chan- nel LINE INPUTS (1) on the front panel of the unit. Connect an XLR balanced cable to the corresponding channel OUTPUT (8) on the rear of the RDI-8 and connect to your chosen destination. If the input signal strength is too “hot” (high) you can depress the 20dB PAD

(6)switch to adjust to a more appropriate level. If there is a ground loop hum you can remove it by depressing the GROUND LIFT (5) switch.

USING THE RDI-8 AS A LINE MIXER

You can mix volume & pan of all input signals simultaneously to both stereo pairs of RCA connections on the rear of the RDI-8: the MASTER (13) and LINE (14) outputs. This enables use of the unit as a fully functional line mixer. This can be very handy for many ap- plications, both live and in the studio. Just connect either or both the stereo MASTER (13) or LINE (14) outputs on the rear to your chosen destination(s), such as a monitor amplifier, and adjust the individual VOLUME (3) and PAN (4) controls for each individual channel on the front of the RDI-8 to suit your needs. A MASTER VOLUME (7) control is provided on the front panel, in addition to the individual controls, and adjusts only the MASTER (13) output. Adjust as necessary.

USING THE RDI-8 PARALLEL CHANNEL LINE OUTPUT

A unbalanced parallel LINK OUTPUT (2) is provided on the front panel next to each LINE INPUT (1) jack. This is useful for routing a direct link out, in addition to the balanced XLR OUTPUT (8) on the rear panel (for example, if you would like to monitor a specific input locally while sending a XLR balanced direct output to another source without affecting the line mixer signal).

SPECIFICATIONS

AUDIO INPUTS
Connectors	1/4" jack
Type	TRS balanced
Impedance	47k Ohms
Min Sensitivity	-20dB
Peak input level	+16dB
PARALLEL LINK OUTPUTS
Connectors	1/4" jack
Type	Unbalanced/parallel
STEREO LINE MIXER OUTPUTS
Connectors	RCA Phono
Impedance	600 Ohms
Max. output level	+2dB (peak level +18.5 dB)
XLR BALANCED OUTPUTS
Connectors	XLR Type balanced
Min. output impedance	600 Ohms
Max. output level	0dB (peak level +18.5dB)
DISTORTION, FREQUENCY RESPONSE,
S/N RATIO & CROSSTALK
Frequency response	20Hz~20kHz, 0dB~-2B
Distortion	0.02%
S/N Ratio	Better than 95dB
Crosstalk rejection	>80dB@1kHz;-20dB input

FUNCTION CONTROLS
Volume	Per channel variable
Volume	Per channel variable
POWER SUPPLY
Power requirement	Selectable, ~ 100-120 VAC,
	~ 200-240 VAC, 50-60 Hz
Power consumption	11.5VA
Fuse	100-120 VAC: 630 mA (slow-blow)
	200-240 VAC: 315 mA (slow-blow)
	100-240 VAC: 500 mA (slow-blow)
	5X20mm glass type
Power cord connector	Standard IEC receptacle
	with built-in fuse holder
PHYSICAL
Dimensions	1.75"X 19"X 8.5" (44.5X482.6X217mm)
Weight	7.15lbs (3.25Kg)

The specifications above are correct at the time of printing of this manual. For improvement purposes, all specifications for this unit, including design and appearance, are subject to change without prior notice.
