Turning on Your microTALK® Radio

10285 PR270-2WX_PH2.qxd 7/24/07 3:50 PM Page 2

Using Your Radio

Operation

Speaker/Microphone/Charge Jack

•

Speaker/Microphone

To attach a speaker/microphone:

/Charge Jack

1. Open the speaker/microphone/charge



tab on top of your microTALK® radio.

2. Insert the speaker/microphone accessory plug into the speaker/microphone/charge jack.

To connect a wall charger/adapter:

1.Open the speaker/microphone/charge tab on top of your microTALK® radio.

2.Insert the wall charger/adapter plug

into the speaker/microphone/charge jack.

Quick Start

1. Press and hold the Mode/Power button to turn on your radio.

2.Press the Channel Up or Channel Down button to select a channel.

Both radios must be tuned to the same channel/privacy code to communicate.

3.Press and hold the Talk button while speaking into the microphone.

4.When finished talking, release the Talk button and listen for a response.

•

Mode/Power Press and hold the Mode/Power button until you hear a series of audible tones indicating the radio

is on.

Your microTALK® radio is now in Standby mode, ready to receive transmissions. The radio is always in Standby mode except when the Talk, Call or Mode/Power buttons are pressed.









Introduction

Operation

Customer Assistance

Warranty

Battery Low

•

Battery Low

When battery power is low, the Battery Low icon



will blink. Your batteries should be replaced or



recharged, if using rechargeable batteries.

Auto Battery Save

•





Battery Save Mode

If there are no transmissions within 10 seconds,



the radio will automatically switch to Battery





Save mode and the Power Saver icon will flash





in the display. This will not affect the radio’s





ability to receive incoming transmissions.



Communicating with Another Person

•



1. Press and hold the Talk button.

Talk Button





2. With the microphone about two inches (5 cm)





from your mouth, speak in a normal voice.





3. Release the Talk button when you are



Two Inches (5 cm)

finished talking and listen for a response.



You cannot receive incoming calls while



from Mouth





pressing the Talk button.





Both radios must be tuned to the





same channel to communicate.



To Select a Channel

•



With the radio on, select any of the

Channel Button





22 channels by pressing the Channel Up





or Channel Down button.





Both radios must be tuned to the



Channel Number

same channel to communicate.









Channels 1 through 7 are shared with FRS/





GMRS. Channels 8 through 14 are FRS only.





Channels 15 through 22 are GMRS only.





See page 14 for FRS/GMRS frequency





allocations and compatibility charts.







Nothing Comes Close to a Cobra® 3

2

Page 3 Page 5
Image 4
Page 3 Page 5
Contents Making Life Easier and Safer Radio while on the goAutomated Help Desk Customer Assistance OperatorsFeatures Product Features Warranty and Trademark AcknowledgementLimited One-Year Warranty on Radios & Charger Rechargeable Batteries and Charger Caring for Your microTALK RadioTo charge batteries in radio To connect a wall charger/adapter Using Your RadioOr Channel Down button Five call tone settings To temporarily turn off auto squelchTo turn maximum range extender on To turn maximum range extender offScrolling Through the Mode Function Set Ctcss Privacy CodesTo select a Ctcss privacy code Privacy CodesMode Functions This will return the radio to Standby mode Channel ScanYour microTALK radio can automatically scan channels To scan channelsFive Call Tone Settings To change a call tone settingOn or off setting is displayed Roger Beep Confirmation ToneGeneral Specifications and Licensing General SpecificationsSafety Information for microTALK Radios Normal PositionProduct Service Product Service Questions

PR 270-2 VP specifications

The Cobra Electronics PR 270-2 VP is an advanced two-way radio that provides exceptional communication capabilities for users across various industries, as well as for recreational activities. This model stands out in the market for its robust feature set, user-friendly design, and impressive range.

One of the main features of the PR 270-2 VP is its 22-channel capability, which ensures you can find a clear communication channel with minimal interference. Furthermore, it includes 121 privacy codes, providing additional security and reducing the likelihood of unwanted transmission from other users. This feature is particularly beneficial in crowded areas where multiple users might be operating on the same channel.

The radio boasts a powerful range of up to 28 miles in optimal conditions, allowing users to communicate effectively over long distances. The actual range can vary based on terrain and environmental factors, but the high power output generally provides reliable communication even in challenging locations.

In terms of technology, the Cobra PR 270-2 VP features a built-in NOAA weather radio with alert functionality. This means users can stay informed about severe weather conditions, enhancing safety during outdoor activities. The weather alerts are critical for anyone who may find themselves in remote areas and need timely updates on changing weather patterns.

Another impressive characteristic of the PR 270-2 VP is its ergonomic design along with a durable and rugged construction. It is built to withstand the rigors of outdoor use, making it an ideal choice for hikers, campers, and outdoor enthusiasts. The radio also features a backlit LCD screen for easy visibility in low-light conditions, allowing for quick adjustments even at night.

Additionally, the Cobra PR 270-2 VP offers hands-free operation with VOX (voice-activated transmission) capabilities. This feature is particularly useful for users who need to keep their hands free while engaging in other activities. The built-in speaker and microphone ensure clear sound quality throughout conversations.

Overall, the Cobra Electronics PR 270-2 VP encapsulates the ideal blend of performance, technology, and user-friendly features. Whether for work or play, it provides dependable communication solutions to keep users connected in any situation, making it an exceptional choice in the realm of two-way radios.
