Cisco Systems 1.1 manual Enabling or Disabling Types of Access to Your DMP

Page 27

Chapter 2 Using DMPDM

Configuring Settings

Table 2-5

GUI Elements on the DMP Display Dimensions Page (continued)







Element



Description





Displayable Width (in

The total width in pixels of your DMP display. The maximum value is 4096 pixels.

relative units)



• Reduce the value to reduce the width of displayed content.









• Increase the value to increase the width of displayed content.





Displayable Height (in

The total height in pixels of your DMP display. The maximum value is 4096 pixels.

relative units)



• Reduce the value to reduce the height of displayed content.









• Increase the value to increase the height of displayed content.







Enabling or Disabling Types of Access to Your DMP

You can enable or disable various kinds of administrative access to your DMP.

Step 1 In the Settings list, click Management Services.

Step 2 Enter or edit the required values, as described in Table 2-6, then click Apply.

Step 3 Select Administration > Save Configuration and, when the Save Configuration page appears, click Save.

Step 4 Restart your DMP. See Restarting Your DMP, page 2-22.

Note If you use the FTP service to save a file to /tmp/ftproot/, the file will be deleted automatically the next time your DMP restarts. If you want the file to persist, upload it to /tmp/ftproot/usb_1/, instead.

Table 2-6

GUI Elements on the Management Services Page

Element

Description

Management Services

Enable Cisco TAC Troubleshooting Access

Indicates whether DMP login access is enabled or disabled for Cisco technical support staff.

•Enabled — Your DMP allows Cisco technical support staff to log in.

•Disabled — Your DMP does not allow Cisco technical support staff to log in.

This feature is enabled by default but, in most cases, we do not support any use of this feature by anyone except a Cisco employee.

Note This feature must be enabled during firmware upgrades. For information about upgrading your DMP firmware, see Upgrading the DMP Firmware, page 2-22.





User Guide for Cisco Digital Media Player Device Manager 1.1













OL-13985-01





2-11
