Auto speaker setup Step | Panasonic SC-HT65 instruction

Auto speaker setup

•Turn off all components before making any connections.

•Peripheral equipment and cables sold separately unless otherwise indicated.

•To connect equipment, refer to the appropriate operating instructions.

Auto speaker setup allows you to achieve a satisfactory listening environment easily with the use of the supplied calibration microphone as a detector of sound signals. The unit will ﬁrst perform automatic speaker detection, then checks and adjusts the following settings.

	DETECTION		• Checks which speakers you have connected. For manual setup, “Speaker size”,
	DETECTION		➡ page 13.
			➡ page 13.

	DISTANCE		• Checks the distance of each speaker from the listening position and adjusts the
	DISTANCE		timing of each channel. For manual setup, “Distance”, ➡ page 13.


	SIZE		• Calibrates based on small speaker conﬁguration.

			• Sets the appropriate low frequency crossover for each channel according to the
	FREQUENCY		speaker size. For manual setup, “Filter”, ➡ page 12.
	FREQUENCY		• The setting is based on the speaker bass reproduction range.

			• Also checks on “Level” setting to adjust for each speaker.

	LEVEL		• Makes any further corrections to the volume of each speaker and also to the
	LEVEL		frequency response.
			frequency response.

Loud test tones are output from the speakers during setup, so keep children out of the room. Before setup

•Conduct the auto speaker setup in a quiet environment. A noisy background will give unsatisfactory results.

•Put the subwoofer in position, switch it on, and sets its volume to the level you would normally use.

Process for auto speaker setup

 Turn on the unit.

Press

•The standby indicator goes off when you turn on the unit.

Auto speaker setup STEP 4

Connect the calibration microphone to the [SETUP MIC] jack on the front panel.

Note

The calibration microphone is sensitive to heat. Keep it away from direct sunlight and do not place it on top of the unit.

Calibration microphone (included)

MENU TUNE

SETUP ENTER

RETURN

SETUP MIC

Placing of calibration microphone.

•Place on a ﬂat surface at the seating area.

•Set calibration microphone position at your ear height.

•Use a tripod for best results.

RQTV0225

SC-HT65 GN-En.indb 11

8/17/2007 4:20:10 PM

SC-HT65 specifications

The Panasonic SC-HT65 is a stylish and versatile home theater system designed to elevate your audio-visual experience. This system is characterized by its sleek design and the ability to deliver exceptional sound quality, making it a perfect addition to any home entertainment setup.

One of the standout features of the SC-HT65 is its powerful audio performance. It incorporates a 5.1 channel surround sound system, which includes a subwoofer and multiple satellite speakers. This configuration allows for a rich and immersive audio experience, perfect for movies, music, and gaming. The subwoofer provides deep bass that enhances the overall soundstage, making every explosion and musical note feel more realistic.

In terms of connectivity, the Panasonic SC-HT65 is well-equipped to handle various input sources. It features multiple HDMI ports, allowing you to connect various devices like Blu-ray players, gaming consoles, and streaming devices. Additionally, it supports optical and coaxial inputs, catering to users who prefer wired connections. The system also includes Bluetooth, enabling wireless streaming from smartphones and tablets, providing flexibility and convenience for users who enjoy listening to music on the go.

The SC-HT65 is equipped with several advanced audio technologies, such as Dolby Digital and DTS decoding. These technologies enhance the overall sound quality by delivering multi-channel audio that fills the room, pulling listeners into the action. The system also features Panasonic’s unique audio processing algorithms designed to optimize sound according to the content being played, ensuring an enriched listening experience.

For added convenience, the Panasonic SC-HT65 includes a user-friendly interface that makes it easy to navigate settings, adjust sound levels, and switch between input sources. Its compact design allows it to fit seamlessly into any room, whether mounted on a wall or placed on a shelf.

In conclusion, the Panasonic SC-HT65 is an impressive home theater system that combines style, flexibility, and advanced audio technologies. With its powerful surround sound capabilities, extensive connectivity options, and user-friendly features, it is well-suited for anyone looking to enhance their home entertainment experience. Whether you're watching movies, enjoying music, or playing video games, the SC-HT65 is designed to deliver an outstanding audio-visual performance that won't disappoint.
