Router Bit Sets

234

ROUTER BITS & SETS

New

ShadowBox

Six Piece Slot Cutter Sets

Application: Produce precision slots for T molding, spline joints, and several other applications

•Includes four three-wing slot cutters (1/16", 1/8", 5/32", and 1/4" kerf), a ball bearing (62-108) to provide a 9/16" depth of cut, an arbor and an attractive wooden storage box.

•Slotting cutters produce precision slots for T-molding, spline joints, and many other applications.

•Cuts all composition materials, plywoods, hardwoods, and softwoods.

•56-109 can be used for biscuit joining.

# 89-300

Slot Cutter's Profile



Bit Type

Item

Overall

Bore

Carbide

Shank





Number

Dia.

Dia.

Height

Dia.



Item Number 89-300















Three Wing Slot Cutter

56-100

2"

5/16"

1/16"

–





Three Wing Slot Cutter

56-108

2"

5/16"

1/8"

–



Three Wing Slot Cutter

56-109

2"

5/16"

5/32"

–





Three Wing Slot Cutter

56-112

2"

5/16"

1/4"

–



Ball Bearing

62-108

22mm (7/8") 8mm (5/16")

–

–





1⁄4" Arbor

60-100

–

–

–

1/4"





Item Number 89-350















Three Wing Slot Cutter

56-100

2"

5/16"

1/16"

–





Three Wing Slot Cutter

56-108

2"

5/16"

1/8"

–





Three Wing Slot Cutter

56-109

2"

5/16"

5/32"

–



Three Wing Slot Cutter

56-112

2"

5/16"

1/4"

–





Ball Bearing

62-108

22mm(7/8") 8mm(5/16")

–

–



1⁄2" Arbor

60-102

–

–

–

1/2"



Six Piece Straight Bit Set

Application: Allows you to make grooves, dadoes, and rabbets

• Sizes range from 1/4" diameter to 1" diameter in 1/8" increments.

• All bits have 1/2" shanks.

• Includes attractive wooden storage box.

• Cuts all composition materials, plywoods, hardwoods, and softwoods.

# 91-102• Use on hand-held and table-mounted portable routers.

Double Flute

Straight Bit Profile



Bit Type

Item

Overall

Carbide

Shank

Overall





Number

Dia.

Height

Dia.

Length



Item Number 91-102















Double Flute Straight Bit

12-100

1/4"

3/4"

1/2"

2-3/8"





Double Flute Straight Bit

12-106

5/16"

1"

1/2"

2-3/4"





Double Flute Straight Bit

12-116

1/2"

1"

1/2"

2-5/8"





Double Flute Straight Bit

12-136

5/8"

1"

1/2"

2-1/2"





Double Flute Straight Bit

12-152

3/4"

1"

1/2"

2-1/2"





Double Flute Straight Bit

12-172

1"

1-1/4"

1/2"

3"





See individual bit for scale profile



Red Item Numbers Indicate 1/2" Shank
