Freud Tools 222 manual Five Piece Cabinet Bit Set, Five Piece Cabinet & Molding Bit Set

Page 8

Five Piece Cabinet Bit Set

New







Storage

Box





s

e

d

i







a







R









o

l

Do rs

e



n



a



P



Video-CD Included

# 94-100

Mad e

S

i

m p l e

Application: Produce your own cabinet doors at a fraction of the cost of shaper heads

•All bits have 1/2" shanks and are designed to be used on 3/4" stock.

•Includes attractive wooden storage box.

•Cuts all composition materials, plywoods, hardwoods, and softwoods.

•Use on table-mounted portable routers with 1/2" shank.

Bit Sets





# 99-001



# 99-510



# 99-031



# 99-260



































Bit Type

Item

Overall

Cut

Small

Carbide

Minor

Large

Small

Angle

Shank

Overall







Number

Dia.

Depth

Dia.

Height

Height

Radius

Radius



Dia.

Length





Item Number 94-100



























Door Lip Bit

99-001

2"

29/64"

–

1-1/4"

11/16"

3/8"

–

7°

1/2"

2-3/4"





2 + 2 Raised Panel Bit

99-510

2-3/4"

–

–

5/8"

7/32"

35/64"

1/8"

–

1/2"

2-1/2"





Reversible Glue Joint Bit

99-031

1-1/2"

–

1-3/16" 1-1/4"

23/64"

–

–

30°

1/2"

2-3/4"





Rail & Stile Bit Set

99-260

1-11/16"

–

1-5/16"

11/16"

15/64"

7/32"

–

–

1/2"

3"



Router

New

Storage

Box

# 95-100

Five Piece Cabinet & Molding Bit Set

Application: Create your own cabinet doors and more than 39 molding patterns

•All bits have 1/2" shanks and are designed to be used on 3/4" stock.

•Includes attractive wooden storage box.

•Cuts all composition materials, plywoods, hardwoods, and softwoods.

•Use on shank table-mounted portable router with 1/2" shank.

229

# 99-510



# 99-031





# 99-260





































# 99-PK1





































Bit Type

Item

Overall

Small

Carbide

Minor

Large

Small

Small

Angle

Shank

Overall







Number

Dia.

Dia.

Height

Height

Radius

Radius1

Radius2

Dia.

Length





Item Number 95-100



























Reversible Glue Joint Bit

99-031

1-1/2"

1-3/16" 1-1/4"

23/64"

–

–

–

30°

1/2"

2-3/4"





2 + 2 Raised Panel Bit

99-510

2-3/4"

–

5/8"

7/32"

35/64"

1/8"

–

–

1/2"

2-1/2"





Multi-Profile Bit

99-PK1

2-5/32"

–

1-59/64"

–

25/64"

5/16"

15/64"

–

1/2"

4"





Rail & Stile Bit Set

99-260

1-11/16"

1-5/16" 1-1/16"

15/64"

7/32"

–

–

–

1/2"

3"



Red Item Numbers Indicate 1/2" Shank

See individual bit for scale profile

ROUTER BITS & SETS

Page 7 Page 9
Image 8
