Technical Specifications

Preset Video Modes

This monitor automatically recognizes many preset video input modes that appear properly sized and centered on the screen. The following modes are assigned at the factory and are the most commonly used display resolutions:

HP f2105 supports preset modes 1 through 21.

Factory Preset Video Input Modes





Horizontal

Vertical

Preset

Pixel format

frequency (kHz)

frequency (Hz)









1

640 x 480

31.5

59.9









2

640 x 480

37.5

75.0









3

720 x 400

31.5

70.1









4

800 x 600

37.9

60.3









5

800 x 600

46.9

75.0









6

832 x 624

49.7

74.6









7

1024 x 768

48.4

60.0









8

1024 x 768

60.0

75.0









9

1024 x 768

68.7

85.0









10

1152 x 720

44.9

60.0









11

1152 x 870

68.7

75.1









12

1152 x 900

61.8

66.0









13

1280 x 768

47.4

60.0









14

1280 x 960

60.0

60.0









15

1280 x 1024

64.0

60.0









User’s Guide

B–3
