Samsung EC-S1065SBA/FR, EC-S1065PBA/FR manual How to use the Manual mode ¸

Page 18

Starting the recording mode

How to use the Manual mode ( ¸ )

You can manually configure all functions aperture value and shutter speed.

1. Select the MANUAL mode by rotating the mode dial.

2. Press the Fn button and menu for the shutter speed and aperture value will display.

Up / Down button : changes aperture value

Left / Right button : changes shutter speed.

3. Press the Fn button twice and take an image.

How to use the DIS mode (

)

Digital Image Stabilisation (DIS) mode.

This mode will reduce the effect of camera shake and help you get a well-exposed image in dim conditions.

Things to watch out for using the DIS mode

1. The digital zoom will not operate in the DIS mode.

2. If the lighting condition is brighter than fluorescent lighting conditions, the DIS will not activate.

3. If the lighting condition is darker than in fluorescent lighting conditions, cam- era shake warning indicator ( Ã) will display. For best results only take pictures in situations where the camera shake warning indicator ( Ã) is not displayed.

4.If the subject is moving, the captured image may be blurred.

5.Avoid moving the camera while the [Capturing!] message is displayed to achieve a better result.

6.As the DIS uses the camera's digital signal processor, it may take a little longer for the camera to process and save the images.

7.If the image size is (;) or (.) ,the DIS mode can’t be selected.

ÄDIS (Digital Image Stabilisation) function does not operate while the camera is connected to a TV. Remember to keep the camera steady when you are taking pictures.

02 RECORDING

RECORDING_ 17
