Samsung HT-C6500/XEF Changing the Camera Angle, Selecting the Picture Setting, Caption Function

Page 47

Caption Function

x

You must have some experience with video extraction and editing in order to use this feature properly.

To use the caption function, save the caption file (*.smi) in the same file name as that of the DivX media f le (*.avi) within the same folder.

Example. Root Samsung_007CD1.avi Samsung_007CD1.smi

Up to 60 alphanumeric characters or 30 East Asian characters (2 byte characters such as Korean and Chinese) for the file name.

Changing the Camera Angle

hZ

When a Blu-ray Disc/DVD contains multiple angles of a particular scene, you can use the ANGLE function.

1.During playback, press the TOOLS button.

2.Press the ▲▼ buttons to select Angle.

3.Press the ◄► buttons to select the desired Angle.

Selecting the Picture Setting

hzZy

This function enables you to adjust video quality when you are connected to a TV via HDMI.

1.During playback, press the TOOLS button.

2.Press the ▲▼ buttons to select Picture Setting, then press the ENTER button.

3.Press the ◄► buttons to select the desired Picture Setting, then press the ENTER button.

Dynamic : Choose this setting to increase Sharpness.

Normal : Choose this setting for most viewing applications.

Movie : This is the best setting for watching movies.



04

User : The user can adjust the sharpness

Basic



and noise reduction function respectively.

Functions

Setting the BONUSVIEW



h

The BONUSVIEW feature allows you to view additional content (such as commentaries) in a small screen window while the movie is playing. This function is only available if the disc has the bonusview feature.

Primary a audio/video

Secondary a audio/video

1.During playback, press the TOOLS button.

2.Press the ▲▼ buttons to select BONUSVIEW Video or BONUSVIEW Audio.

3.Press the ◄► buttons to select the desired bonusview.

NOTE

If you switch from BONUSVIEW Video, BONUSVIEW Audio will change automatically in accordance with BONUSVIEW Video.

Tools

BONUSVIEW Video

Off

BONUSVIEW Audio :

0/1 Off

Picture Setting



<Change " Select

English 47

HT-C6500_ELS_0203.indd 47

2010-02-03 ￿￿ 11:14:54

Image 47
