Setup

If you want to display Initial Settings screen again in order to make changes, press the STOP () button on the front panel of the product for more than 5 seconds with no disc inserted.

Use the HDMI cable to connect the product to an Anynet+(HDMI-CEC)-compliant Samsung TV. If the TV uses a language supported by the product, that language will be set to a preferred language automatically.

However, the Anynet+(HDMI-CEC) feature should be set to On in both TV and the product.

If the product is left in the stop mode for more than 5 minutes without being operated, a screen saver will appear on your TV. If the product is left in the screen saver mode for more than 25 minutes, the power will automatically turn off except during playback of a CD-DA (Automatic Power-Off Function).

Setting the Menu

1.Press the POWER button. The Home Menu will appear.

Home Menu





You Tube







Please activate Internet@TVinternet radio service







to enjoy a variety of Internet Services.



2

















3









4

1







5









No Disc

a Change Device

d View Devices

" Enter

6

1

Selects the Internet@TV.

2

Selects the Videos.





3

Selects the Music.





4

Selects the Photos.





5

Selects the Settings.





6

Displays buttons available.





1

2

DISC MENU

TOOLS

RETURN

MENU

TITLE MENU

POPUP

INFO

EXIT

TUNER

3

4

2.

Press the ◄► buttons to select Settings,

3.

then press the ENTER button.

Press the ▲▼ buttons to select the desired

4.

submenu, then press the ENTER button.

Press the ▲▼ buttons to select the desired

5.

item, then press the ENTER button.

Press the EXIT button to exit the menu.

NOTE

1MENU Button : Press this to move to the home menu.

2RETURN Button : Return to the previous menu.

ENTER / DIRECTION Button:

Press the arrow buttons to move the cursor and select

3an item.

Press the ENTER button to launch the selected item or confirm the setting.

4EXIT Button : Press this to exit the menu.

When the product is connected to the network, select Internet@TV from the home menu. Download desired content from Samsung AppS.

The access step may differ depending on the selected menu.

The OSD (On Screen Display) may change in this product after upgrading the software version.
