Samsung CE2915N/XSV manual Checking that Your Oven is Operating Correctly

Page 10

GB

Checking that Your Oven is Operating Correctly

The following simple procedure enables you to check that your oven is working correctly at all times.

Open the oven door by pulling on the handle on the right side of the door. Place a glass of water on the turntable. Then, close the door.

Model : CE2975N

Turn the cooking control knob to manual cook

1. Press the button and set the time to 4-5 minutes by turning the dial knob as required.

2.Press button.

Result: The oven heats the water for 4 to 5 minutes.

The water should then be boiling.

Model : CE2915N

Turn the cooking control knob to manual cook

1. Set the power level to maximum by turning COOKING POWER CONTROL knob.

2. Set the time 4 to 5 minutes by turning the TIMER knob. Result: The water should then be boiling.

The oven must be plugged into an appropriate wall socket. The turntable must be in position in the oven. If a power level other than the maximum is used, the water takes longer to boil.

What to Do if You are in Doubt or Have a Problem

If you have any of the problems listed below, try the solutions given.

This is normal.

Condensation inside the oven and display

Air flow around the door and outer casing

Light reflection around the door and outer casing

Steam escaping from around the door or vents

The oven does not start when you press the button.(CE2975N)

Is the door completely closed?

The oven does not start when you turn the TIMER knob.(CE2915N)

Is the door completely closed?

The food is not cooked at all

Have you set the timer correctly and/or pressed the button? (CE2975N)

Have you set the timer correctly? (CE2915N)

Is the door closed?

Have you overloaded the electric circuit and caused a fuse to blow or a breaker to be triggered?

The food is either overcooked or undercooked

Was the appropriate cooking length set for the type of food?

Was an appropriate power level chosen?

Sparking and cracking occur inside the oven (arcing)

Have you used a dish with metal trimmings?

Have you left a fork or other metal utensil inside the oven?

Is aluminium foil too close to the inside walls?

The oven causes interference with radios or televisions

Slight interference may be observed on televisions or radios when the oven is operating. This is normal.To solve this problem, install the oven away from televisions, radios and aerials.

If interference is detected by the oven’s microprocessor, the display may be reset.To solve this problem, disconnect the power plug and reconnect it. Reset the time.(CE2975N)

If the above guidelines do not enable you to solve the problem, contact your local dealer or SAMSUNG after-sales service.

10

Image 10
