Samsung MM-KT8Q/XFU manual Press REV.MODE until the appropriate symbol is displayed, Power

Page 33

Selecting the cassette Playback Mode/Repeat AB Function

Timer Function

The timer enables you to switch the system on or off at specific times.

If you no longer want the system to be switched on or off automatically, you must cancel the timer.

Before setting the timer, check that the current time is correct.

For each step, you have a few seconds to set the required options. If you exceed this time, you must start again.

Selecting the Cassette Playback Mode

Your micro component system has three cassette playback modes which enable you to listen to both sides of a cassette automatically.

Press REV.MODE until the appropriate symbol is displayed.

RESERVE

CANCLE

REMAIN

Example: You wish to wake up to music every morning.

Switch the system

Press

TIMER/CLOCK

on by pressing

until TIMER is

1 POWER.

2 displayed.

Press the ENTER

3 button.

ON TIME is displayed (instead of the equalizer symbols) for a few seconds, followed by any switch-on time already set; you can set the timer switch-on time.

When the display indicates...The micro component system plays back

One side of the selected cassette and then stops.

One side of the cassette.

The other side of the cassette and then stops.

Both sides of the cassette indefinitely until you press stop.

REPEAT AB Function

Press REP. AB button.

Use this to listen to a specific section again during playback.

Set the start and end points of the section you want to repeat 3 times.

FAVORITE SONG

SEARCH SONG

KEY CONTROL

TUNING MODE

SLOW

b#

TEMPO

TUNER MEMORY

LOGO

-+

FEMALE

4 Set the timer switch-on time.

a. Set the hour by pressing or button.

b. Press ENTER.

The minutes flash.

c.Set the minutes by pressing or button.

d.Press ENTER.

OFF TIME is displayed (instead of the equalizer symbols) for a few seconds, followed by any switch- off time already set; you can now set the timer switch-off time.

5 Set the timer switch-off time.

a. Set the hour by pressing or button.

b. Press ENTER.

The minutes flash.

c.Set the minutes by pressing or button.

d.Press ENTER.

VOL 20 is displayed, where 20 corresponds to the volume already set.

Press or button

6 to adjust the volume level and press

ENTER.

The source to be selected is displayed.

This is a useful when learning a foreign language.

The TAPE REPEAT function can be used only on sections that are longer

than 7 seconds.

Note

You cannot set the end point (B) within 7 seconds after



setting the start point (A).

MALE STEP

Press or button

8

Press ENTER to

to select the source to

confirm the timer.

be played when the

7 system switches on.



TAPE (cassette) : Insert a cassette tape.

TUNER (radio) : a Press ENTER.

b Select a preset station by pressing

Tuning or .

CD (compact disc) : Load a compact disc.

USB :connect the USB.

Press POWER to

9 set the system to standby mode.

is displayed to the top-right of the time, indicating that the timer has been set.

The system will switch on and off automatically at the required times.

MISCELLANEOUS

63

Note

If the timer switch on and off times are identical, the word ERROR is displayed.

64
