5 Installing and Connecting the WP-121

This section explains how to install and connect the WP-121.

5.1Installing the WP-121

To install the WP-121 as illustrated in the example in Figure 4:

1.Connect either the:

Terminal block line output of the WP-121to the pre-installed STP wiring in the wall box opening that connects to the TP receiver —or—

RJ-45 line output of the WP-121to the pre-installed STP wiring in the wall box opening that connects to the TP receiver

2.Recommended—ground the wall plate (see Section 5.3).

3.Connect the 12V DC power supply to the power terminal block taking care

that the polarity is correct.

Connect the wire labeled “+” to the +12V pin, and the wire labeled “–” to the GND pin.

4.Insert the WP-121into the wall box opening and secure the WP-121front panel using the screws.

5.2Connecting the WP-121

To connect the WP-121 as illustrated in the example in Figure 4:

Note: Do not connect both the RJ-45 and terminal block connectors to receivers. If you do so, neither will work.

1.Connect the UXGA source to the PC IN connector (for example, a computer graphics source).

2.Connect the unbalanced stereo source to the AUDIO IN connector (for example, the audio signal from the computer graphics source).

WP-121 - Installing and Connecting the WP-121
