Vermont Castings, Majestic Products DEF/DEFD26

Replacing the Light Bulbs

This fireplace uses two (2) clear 120 Volt, 60 Watt, E-12 socket base light bulbs (small base, chandelier candle type). The 60 Watt bulbs are located under the logset/ember bed. For convenience, if one (1) of the bulbs burns out, it will be prudent to replace both of the light bulbs.

1.Turn OFF power to the unit by unplugging the power cord.

2.Let fireplace cool if it has been operating.

3.Remove the four (4) screws securing the bottom louvre. Pull the louvre up and lift it out.

4.Examine the bulbs to determine which bulb needs to be replaced.

5.While holding the socket, unscrew defective bulb(s).

6.Install the new light bulb(s) by screwing it in while holding the socket.

7.Reinstall the bottom louvre. Follow the above procedure in reverse order.

WARNING: Do not exceed 60 Watts per bulb. Use of higher-rated bulbs may result in a fire, causing property damage or personal injury.

Maintenance of Motors

The motors used on the fan and the flame generator assembly are prelubricated for extended bearing life and require no further lubrication. However, periodic cleaning/vacuuming of the fan/heater unit is recommended.

WARNING: Make sure the power is turned OFF before proceeding.

Trim Kit Installation

1.Peel all plastic from the Trim Kit Assembly.

2.Press the Trim Kit Assembly onto the front of the fireplace. To facilitate the installation process, these pieces are magnetized. Align the top of the Trim Kit Assembly with the top of the fireplace.



DEF26_3D

Fig. 2

Trim kit installation

10005581

7
