MAINTENANCE

ROUTINE MAINTENANCE

•Be sure to stop the operation and disconnect the power source before performing any checks or cleaning.

•Do not wet the air conditioner(s).

•Benzene, thinner and cleaning powder may damage the coated surface or the plastics.

•Do not use water higher than 40° C (104° F), or the air filters may shrink and the plastic materials may be dam- aged.

•Do not touch the evaporator coil when removing and re- placing the air filters. Injury may occur.

•Never operate the unit without the air filters.

How to replace air filters:

A)Place the air filters with “Front” marking facing toward you in the reverse order of mentioned “How to remove air filters”.

B)Gently push to close the front grille to the unit.

C)Secure the grille in position by pressing evenly along the lower edge.

2.CLEANING INDOOR UNIT(S) & REMOTE CONTROL(S)

Use a dry cloth for cleaning the indoor unit(s) and remote control(s).

1. CLEANING AIR FILTERS (ONCE EVERY TWO WEEKS)

Clean the air filters at least once every two weeks to save elec- tricity. Use the vacuum cleaner to remove dust from the air filter.

NOTE: In case the dust on the air filter cannot be easily removed with a vacuum cleaner, use a neutral clean- ing agent. Be sure to sufficiently rinse the air filter with water to completely remove the cleaning agent and allow it to dry in the shade.

How to remove air filters:

A)Pull the front grille by grasping the recesses on the ends.

B)Open the front grille up to the position where it is stopped with a click sound.

C)Raise the air filter, disengage the claws, and remove.

BEFORE THE SEASON

•Check that the air inlet and outlet of the indoor and outdoor units are not blocked.

•Check that the ground wire is connected and there is no wire breaks anywhere.

•Check that the installation bracket is not corroded or rusty.

•Check that the air filters are clean and in place.

AFTER THE SEASON

•Operate on “CIRCULATION” only mode for several hours on a dry day. Storage when wet will allow mold to develop.

•Disconnect the power source

•Remove the batteries from the remote control.

•Clean the air filters and replace.

BEFORE CALLING FOR SERVICE

THE FOLLOWING ARE NOT DEFECTS

•A hissing noise or hollow sound:

This sound may be generated from the refrigerant flowing within pipes during operation or after turning off the unit(s).

•A squeaking noise:

This noise is generated from the air conditioner(s) when it expands or contracts due to temperature changes.

•A rustling noise:

This noise is generated from the indoor fan at start up.

•Operating sounds may change:

The operation sounds varies with the fan speed.

•Odors:

Such odors as tobacco, cosmetics, or foods may accumu- late in the indoor unit(s).

•Indoor fan motor(s) stop:

In the “AUTO”, “DRY” and “HEAT” operation mode, the in- door fan motor(s) will be stopped when the room tem- perature reaches the set temperature.

•The air conditioner(s) do not start or change operation mode immediately:

To prevent overloading the compressors, the air conditioner(s) will not start for approx. 3 minutes.

•No change on the operation mode by the remote control: The signal of operation mode changing has not reached the indoor unit(s). Press the ON/OFF button again and change the operation mode.

•The fan speed of the indoor fan motor changes or the fan motor of the outdoor unit stops:

To prevent overloading the unit, the air conditioner(s) may change the indoor fan speed and operate the outdoor fan intermittently.

•In heat mode water comes out the outdoor unit:

The ambient air can condense on the pipes of the outdoor unit.

ECR International

9

Hyundai Ductless Split System

Page 8 Page 10
Image 9
