Installation

Position

Place the freezer horizontally on a firm surface, resting on all wheels. Use a wooden block or similar object to compensate for any bumps/holes in the surface.

The room should be dry and adequate- ly ventilated.

Temperatures of the external environment have an impact on the energy consump- tion of the freezer. Therefore:

-do not place the freezer in a position exposed to sunshine or beside a radiator oven, or any other source of heat.

-position it where the temperature of the environment corresponds to the climatic classification for which the

freezer was designed.

Climatic classification Ambient temperature limits

SN

From….to

+10 to +32 C

N+16 to +32 C

ST

+18 to +38 C

T+18 to +43 C

If the freezer has been handled in a vertical position it should be allowed to stand in normal position for about 12 hours before switching it on.

Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of a breakdown.

Electrical requirements

Before switching on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate, located on the back of the cabinet.

electrolux cold 9

Warning:

This appliance must be earthed.

This appliance complies with the

following EC Directives:

-73/23/EEC-Low-VoltageDirective -89/336/EEC -EMC Directive.

Testing has been carried out in accordance with EN 153 regarding the determination of freezer capacity,energy consumption and temperature rise time.

Description of equipment

Control panel:

1.Signal lamp of the control section (green).

2.Signal lamp (yellow) for quick freezing.

3.Acoustic alarm and alarm signal lamp (red).

4.Push button:

-for reset acoustic alarm

-for start quick freezing mode

-for stop quick freezing mode

Electrical Connection

Any electrical work required to install this appliance should be carried out by a qualified electrician or compe-

tent person.

This appliance must be earthed.
