KitchenAid KBLS36FKB01, KBLS36FKW01, KBLS36FKT01, KBLS36FKX01 manual Illus. Part No. No. Description

Page 6

LINER PARTS

For Models: KBLS36FKB01, KBLS36FKT01, KBLS36FKW01, KBLS36FKX01

(Black)

(Biscuit)

(White) (Etched Aluminum)

Illus. Part

No. No. DESCRIPTION

1Liner, Refrigerator (Not Servicable)

2Liner,Freezer (Not Servicable)

32215610 Cover, Heat Exchanger

42215827 Diffuser Cap, Left Side

52005931 Diffuser Cap, Right Side

62171846 Release Valve

7487539 Screw, 8−15 x 1/2

8486194 Screw

92208968 Motor, Grommet

102006148 Wiring Channel, Freezer Rear

112215844 Foam, Fan Shroud

122215910 Grommet, Flexible

132215606 Shroud, Evaporator Fan

142169142 Blade, Fan

152208939 Motor, Fan

162155590 Retainer,

Fan Motor

Illus. Part

No. No. DESCRIPTION

172221296 Air Baffle Assembly

182215503 Bracket

198201595 Wiring Channel

202221261 Wiring Harness, Freezer

212215833 Cover, Evaporator Assembly

221116793 Cover, Thermistor

232213442 Thermistor

242209208 Drain Tube, Condensate

252215530 Insulation, Baffle

262215531 Cover, Air Diffuser

272204595 Heater−Tube, Drain

282204538 Insulation, Tube

Drain

292204537 Cover, Tube Drain

312215835 Housing, Switch

321157158 Screw, 8−18 x 3/8

332187377 Wire, Jumper

35 2209204 Clip, Thermistor

Illus. Part

No. No. DESCRIPTION

362215612 Cover, Air Duct

372215816 Control Panel

382221064 Overlay, Control

Panel

392209159 Circuit Board (User Interface)

402215670 Insert, Control

Box

41489464 Screw

422162085 Socket, Light

432160708 Light Bulb

442187424 Harness, Control Box

458201534 Channel, Wiring Freezer Light

461115375 Clip, Wiring

471115373 Switch, Rocker

482005792 Wiring Cover, Icemaker

492187378 Defrost Bi−Metal

502215829 Diffuser Assembly

512221121 Support, Control Box

52489006 Screw

6

8198081

Image 6
