Roberts Radio RD-1 manual Display settings Backlight

Page 47

Display settings - Backlight

This can be set to Off (always off), On (always on), On with AC (on when using AC adaptor) or Keypress (backlight switches on for 12 seconds following any key press).

Note: If backlight is set to On (always on) battery life will be reduced.

1.Press the Setup button to enter Setup menu.

2.Rotate the Tuning control until the Display section appears between the two black lines on the display. Press in and release the Tuning control to confirm the selection

3.Rotate the Tuning control until the Backlight line is highlighted in the display.

4.Press in and release the Tuning control to enter adjustment mode. Rotate the Tuning control to select required backlight mode e.g. On, Off, On with AC or Keypress.

5.Press in and release the Tuning control to confirm the selection.

6.Repeatedly press and release the Setup button until the display returns to show normal station mode.

Set-up

1

TUNING

Press

to select

2

TUNING

Press

to select

4

Set-up

AUTO

Set-Up

Buzzer Alarm

Radio Alarm

Record Timer

AUTO

Set-Up

Clock

DAB

Display

Sleep

Keypress

	AUTO
	Display
Display Saving	No
Backlight	On With AC
Contrast	12

AUTO

BBC 7

The Brighton Mystery Journalist Polly solves murder mysteries with the help of a mystery Man in a tea room

6

If you need any further advice, please call our Technical Helpline on :-

11:1018-May-2004

020 8758 0338 (Mon-Fri)	46
