Miele CS1212 installation instructions Safety distances to the sides of the appliance

Page 32

SAFETY INSTRUCTIONS FOR INSTALLATION

Safety distances to the sides of the appliance

The appliance should only be installed as shown in the illustrations, while maintaining the required safety distances shown. Do not install the appliance between two tall cabinets, this is a fire hazard.

A distance of at least 2" (50 mm) must be kept between the countertop cut-out and the rear wall because of the high temperatures radiated.

The minimum distance a between the worktop cut-out and a wall or tall unit to the right or left of it is:

2" (50 mm)

for

CS 1112





CS 1122





CS 1212





CS 1221





CS 1223





CS 1326





CS 1411

6" (150 mm)

for

CS 1312





CS 1322





CS 1421

10" (250 mm) for

CS 1011





CS 1012





CS 1028

2 " (50 mm)

recommended

2" (50mm)

1

not recommended

not permitted

32

Image 32
