Operating your SAMSUNG French Door Refrigerator

Using the control panel

1

4

2

5

3

6

G ATIN OPER 02

7 8

( 1 ) Energy Saver Button

For better energy efficiency, press the Energy Saver button. If condensation occurs on the doors, turn the Energy Saver function off.





( 2 ) Freezer/Hold 3 sec for Power Freeze Button

Press the Freezer/Hold 3 sec for Power Freeze button to set the Freezer to your desired temperature. You can set the temperature between 8°F and -8°F.

Press and hold the Freezer/Hold 3 sec for Power Freeze button for 3 seconds, to speed up the time needed to freeze products in the Freezer. It can be helpful if you need to quickly freeze easily spoiled items or if the temperature in the Freezer has warmed dramatically (For example, if the door was left open).

(

3 ) Alarm/Hold 3 sec for

Press the Alarm button to turn off the door open alarm. After removing the old water filter and installing a new one, reset the

Indicator by pressing and holing the “Alarm” button for 3seconds.



Filter Reset Button



The indicator will light again in about 6months to let you know it is Time to change your water filter.















Press the Lighting button to turn on the Dispenser LED lamp.

(

4 ) Lighting Button







( 5 ) Fridge/Hold 3 sec for Power Cool Button

Press the Fridge/Hold 3 sec for Power Cool button to set the fridge to your desired temperature. You can set the temperature between 34°F and 46°F.

Press and hold the Fridge/Hold 3 sec for Power Cool button for 3 seconds, to speed up the time needed to cool products in the Refrigerator. It can be helpful if you need to quickly cool easily spoiled items or if the temperature in the fridge has warmed dramatically (For example, if the door was left open).

( 6 ) Ice Off / Hold 3 sec to

Press the Ice Off button to turn the ice making function off.

Child Lock

If you press and hold the Ice Off button for 3 seconds, the Display and Dispenser will be locked.





Press the Ice Type button to select your desired ice type. Cubed and crushed ice modes will be alternatively changed whenever you

( 7 ) Ice Type Button press the button. After selecting, push the Dispenser Lever gently with your glass. This mode can not be used with the Water mode simultaneously.

(

8 ) Water Button

Press the Water button to dispense water. There is no Off mode additionally. After selecting, push the Dispenser Lever gently with your

glass. This button can not be used with the Ice Type button simultaneously. Water mode will be off if you press the Ice Type button.











Cooling off stops cooling in the freezer and refrigerator compartments, but does not shut off electrical power to the refrigerator. To use

( 1 , 2 ) COOLING OFF this feature , press Energy Saver Button and Freezer/Hold 3 sec for Power Freeze Button simultaneously for 3 seconds until an alarm sound is heard. To cancel this mode, press the same buttons again for 3 seconds. Even though power is turned off and then

back on, it remain in Cooling off mode.

Operating _21
