Instructions for use

The different functions offered by the oven are selected by operating the controls and devices situated on the oven panel.

Attention: before using the oven and grill for the first time, turn the oven on for approximately one half hour. Make sure that the oven is empty, the thermostat on high, the door open, and the room properly ventilated. The odor which can be detected at times is due to the evaporation off the substances used to protect the oven and the grill during the period between the and installation of the appliance.

Attention: Only use the bottom shelf of the oven when using the rotisserie to cook (where present). For all other types of cooking, never use the bottom shelf and never place anything on the bottom of the oven when it is in operation because this could damage the enamel. Always place your cookware (dishes, aluminium foil, etc. etc.) on the grate provided with the appliance inserted especially along the oven guides.

The oven knobs

With these two controls you can select the different functions of the oven and choose the cooking temperatu- re suitable for the food you are preparing. The different cooking functions are set up by operating the two knobs:

E - the selection knob (identified by the symbol )

F - the thermostat knob (identified by the symbol ) on the oven panel.

For any selection-knob setting different from idle, identified by the “0”, the oven light turns on; the knob setting marked

permits turning on the oven light without any heating element being switched on.

1. Coventional

-Knob “E” setting:

-Knob “F” setting: anywhere between 60°C and Max

The oven light turns on and the top and bottom heating elements (resistors) switch on. The temperature, fixed by the thermostat knob, is reached automatically and kept constant by the thermostat control. This function permits cooking and type of food thanks to excellent temperature distribution.

2. Pastry

-Knob “E” setting:

-Knob “F” setting: anywhere between 60°C and Max

The oven light turns on and so does the bottom heating element. The temperature, fixed by the thermostat knob, is reached automatically and kept constant. This setting is recommended for finishing the cooking of foods (placed in pans) that are well done on the outside but still not done inside or for desserts covered with fruit or jam which require a light browning on top. Note that this function does not permit reaching the maximum (250°C) temperature inside for cooking foods always on this oven setting unless the foods are cakes which only require temperatures below or equal to 180°C.

3. The grill

-Knob “E” setting:

-Knob “F” setting: Max

The oven light turns on and so does the infra-red ray grill. The rather high and direct temperature of the grill permits browning the outside of meats immediately thus keeping in the juices and assuring tenderness.

4. The double grill

-Knob “E” setting:

-Knob “F” setting: Max

The oven light turns on and so does the double heating element of the grill. This grill is larger than the average and has a completely new design: cooking performance is increased 50%. The double grill makes sure that even the corners are touched by heat.

The oven-operating pilot lamp (G)

Signals when the oven is heating. It switches off when the temperature inside the oven reached the temperature selected by the knob. At this point the alternate turning on and turning off of this light indicates that the thermostat is operating correctly to keep the oven temperature constant.

Handle

Attention: when the oven is on steam escapes from the slot on the right end of the handle. Keep hands away from this area. For ovens with tubular handles, there is a special protective device which is fitted during cooking to keep steam away from the front of the cooker.

Forced Air Ventilation

In order to reduce the external temperature of the oven, some models have been equipped with a cooling fan which comes on when the "E" knob is turned to a cooking setting. The fan remains on during the cooking process and a flow of air can be heard exiting between the oven door and the control panel.

Note: When cooking is over, the fan remains on for a few minutes, in order to enable the oven to cool down quickly.

3rd glass-door

You can buy a special kit to reduce door temperature when the oven is on and save energy. If there are little children in the house, this kit is a must. The kit code number is 074657 and it may be purchased for installation from an authorised dealer or a Technical Assistance Service centre indicated in the list included with the appliance documents.
