John Lewis JLBIOS610 instruction manual Oven door glass and water collecting channel

Page 26

5.Put the metal frame and seal back in place, insert screws, and tighten.

6.Replace the side rails.

Removing the door glass and water collecting channel

1. Open the oven door as far as it will go.

90°

2.Undo the clamping levers (A) on both door hinges fully .

3.Close the oven door as far as the first position (approx. 45°).

Oven door glass and water collecting channel

The oven door is fitted with three panels of glass mounted one behind the other and a water collecting channel. The inner panels and the water collecting channel can be removed for cleaning.

Important! Rough handling, especially around the edges of the front panel, can cause the glass to break.

4.Take hold of the door trim (B) on the upper edge of the door at both sides and press inwards to release the clip seal. Then remove the door trim by pulling upwards.

Image 26
