Command Functions

The C-5xeMPmay either be controlled by the remote control handset via a receiver on the front panel or by a system controller via the control port. A small toggle switch on the rear panel selects which mode is active.

For normal use, set this switch to “IR Receiver”. Set the switch to “Control Port” only when using a custom programmed system controller.

Command files are available from the Ayre factory in both Crestron and Pronto (CCF) format. These files include discrete on/off commands.

Power Status Information

The control port will also transmit the current power status (”Operate” or “Standby”) of the C-5xeMPinformation to a system controller. This feedback ensures that system controller remains synchronized with the actual state of the unit.

31
