U-Line ADA24RGL manual Troubleshooting Models with an electronic display

Page 16

ADA SERIES

Troubleshooting - Models with an electronic display:

PROBLEM

POSSIBLE CAUSE

REMEDY







Electronic display is blank and

Unit is in blackout/Sabbath mode

Exit blackout/Sabbath mode (not Star K certified)

interior light is off with door open.

(not Star K certified).

(See OPERATION).







Electronic display is blank and

A display function has changed.

Touch and hold the WARMER button and touch and

interior light is on with door open.



release the ON/OFF button three times, then release the





temperature button. The display should become visible.







Electronic display shows repeating,

A factory control mode has been

Touch and hold the warmer temperature button and

randomly flashing symbols and

inadvertently entered.

touch and release the LIGHT button three times, then

partial characters.



release the temperature button to exit the factory





control mode. The set-point temperature should now





be displayed.







Electronic display shows:

A factory control mode has been

Repeatedly touch the WARMER button to advance any

0, 1 to 16, or 99.

inadvertently entered.

number shown to 99 and touch and release the LIGHT





button. The set-point temperature should now be





displayed.







Electronic display shows one or

The unit is displaying an error code.

Record the error code(s) displayed and call for service.

more of the following:





E1, E2, E4, E5, E6.











14

ADA24

Image 16
