Whirlpool GS773LXS Oven USE, Aluminum Foil, Oven Temperature Control, Add 1 Minute on some models

Page 10

Style 1 - Electronic Oven Control

Control lockout

Control lockout icon

To Lock Controls:

1.Check that the oven is off and no delayed timed cooking is programmed.

2.Press and hold CONTROL LOCKOUT for 3 seconds.

A single tone will sound. “Loc,” “LOCKED,” and the control lockout icon will be displayed.

To Unlock Controls:

1.Press and hold CONTROL LOCKOUT for 3 seconds.

A single tone will sound. “Loc,” “LOCKED,” and the control lockout icon will disappear from the display.

Style 2 - Electronic Oven Control

Control lockout

Control lockout icon

To Lock Controls:

1.Check that the oven is off and no delayed timed cooking is programmed.

2.Press and hold CONTROL LOCKOUT for 3 seconds.

A single tone will sound. “Loc” and the control lockout icon will be displayed.

To Unlock Controls:

1.Press and hold CONTROL LOCKOUT for 3 seconds.

A single tone will sound. “Loc” and the control lockout icon will disappear from the display.

Style 3 - Electronic Oven Control

Control Lockout is not available on Style 3 oven controls.

ADJUSTMENT °F

COOKS FOOD

(ADJUSTMENT °C)







10°F (5°C)

...a little more





20°F (10°C)

...moderately more





30°F (15°C)

...much more





-10°F (-5°C)

...a little less





-20°F (-10°C)

...moderately less





-30°F (-15°C)

...much less





To Adjust Oven Temperature Calibration:

1.Press and hold BAKE for 5 seconds until the oven display shows the current calibration, for example “0°F CAL” or “00.”

2.Press the TEMP or TEMP/HOUR “up” or “down” arrow pad(s) to increase or to decrease the temperature in 10°F (5°C) amounts. The adjustment can be set between 30°F (15°C) and -30°F (-15°C).

3.Press START.

OVEN USE

Odors and smoke are normal when the oven is used the first few times, or when it is heavily soiled.

IMPORTANT: The health of some birds is extremely sensitive to the fumes given off. Exposure to the fumes may result in death to certain birds. Always move birds to another closed and well- ventilated room.

Aluminum Foil

IMPORTANT: To avoid permanent damage to the oven bottom finish, do not line the oven bottom with any type of foil, liners or cookware.

■On those models with bottom vents, do not block or cover the oven bottom vents.

■Do not cover entire rack with foil because air must be able to move freely for best cooking results.

■To catch spills, place foil on rack below dish. Make sure foil is at least ¹⁄₂" (1.3 cm) larger than the dish and that it is turned up at the edges.

Add 1 Minute (on some models)

Time may be added to the kitchen Timer in 1-minute increments, up to 12 hours and 59 minutes, by touching the ADD 1 MIN pad.

Touching ADD 1 MIN will add 1 minute of time to the kitchen Timer only.

Oven Temperature Control

IMPORTANT: Do not use a thermometer to measure oven temperature because opening the oven door may cause burner cycling to give incorrect readings.

The oven provides accurate temperatures; however, it may cook faster or slower than your previous oven, so the temperature calibration can be adjusted. It can be changed in Fahrenheit or Celsius.

A minus sign means the oven will be cooler by the displayed amount. The absence of a minus sign means the oven will be warmer by the displayed amount. Use the following chart as a guide.

Positioning Racks and Bakeware

IMPORTANT: To avoid permanent damage to the porcelain finish, do not place food or bakeware directly on the oven door or bottom.

5

4

3

2

1

6

RACKS

■Position racks before turning on the oven.

■Do not move racks with bakeware on them.

■Make sure racks are level.

10
