Page 19

Oven Light

The oven light is a standard 40-watt appliance bulb. Before replacing, make sure the oven and cooktop are cool and the control knobs are in the off position.

To Replace:

1.Unplug range or disconnect power.

2.Turn the glass bulb cover in the back of the oven counterclockwise to remove.

3.Turn bulb counterclockwise to remove from socket.

4.Replace bulb, then bulb cover by turning clockwise.

5.Plug in range or reconnect power.

Oven Door

For normal range use, it is not suggested to remove the oven door. However, if removal is necessary, make sure the oven is off and cool. Then, follow these instructions. The oven door is heavy.

To Remove:

1.Open oven door all the way.

2.Flip up the hinge latch on each side.

3.Close the oven door as far as it will shut.

4.Lift the oven door while holding both sides.

Continue to push the oven door closed and pull it away from the oven door frame.

To Replace:

1.Insert both hanger arms into the door.

2.Open the oven door.

You should hear a “click” as the door is set into place.

3.Move the hinge levers back to the locked position. Check that the door is free to open and close. If it is not, repeat the removal and installation procedures.

Storage Drawer

The storage drawer can be removed. Before removing, make sure drawer is cool and empty.

To Remove:

1.Pull the storage drawer straight back past the drawer stop notch and the end of the side rails.

A B

A. Drawer stop notch

B. End of side rail

2.Lift up the back of the drawer and pull the drawer out.

To Replace:

1.Lift up the back of the drawer and place it inside the range in its fully forward position.

2.Lift up the front of the drawer to a level position.

3.Slowly push the drawer into the range until the drawer side rails engage with the gap in the drawer glides.

A

A. Engage drawer glide.

4.Once the drawer is fully engaged on both sides, slide the drawer back into the closed position.

NOTE: When you are removing and replacing the storage drawer, a slight push may be needed to move the drawer stop notch past the drawer glides.

19
