Cannon 10535G MK2, 10538G MK2, 10530G MK2, 10532G MK2 Unpacking, Levelling, Stability Bracket

Page 21

UNPACKING

Unpack the components from inside the grill and oven: Check that the following parts are present.

Grill pan and grid

Pan supports (4)

Meat tin

Enamelled burner caps (4)

Oven shelves (2)

Literature pack

Battery

Aluminium burner bodies (4)

LEVELLING

Four skid feet are fitted which can be screwed in or out to level the cooker. Move the cooker by pushing at both sides on the lower half of the oven door.

CAUTION: Some soft floor coverings may get damaged if the cooker is not moved carefully.

STABILITY BRACKET

The back of the cooker has a slot for engagement of a stability bracket, which can be obtained, as an extra, from the cooker supplier. The leaflet included with the bracket should be read in conjunction with the following instructions.

Push cooker to its intended position.

Draw pencil lines on the floor in line with the front and left side of the plinth. Remove the cooker.

Position stability bracket in accordance with Fig. 5 and secure to the floor. Measure height from floor level to the bottom of the slot in the back of the cooker.

Add 3mm to the dimension and assemble the stability bracket to that height. (i.e. from floor level to the underside of the top member)

Fig. 5

Fig. 6

‘A’

92

mm‘B’ 410mm

PENCIL LINE

21
