Stovax 1002, 1001, 1000 manual Using the Appliance for the First Time, Recommended Fuels, Wood Logs

Page 6

USER INSTRUCTIONS

WARNING

Properly installed, operated and maintained this appliance will not emit fumes into the room.

Occasional fumes from de-ashing and refuelling may occur.

Persistent fume emission is potentially dangerous and must not be tolerated.

If fume emission does persist:

Open doors and windows to ventilate the room •Allow fire to burn out or safely dispose of fuel from the appliance

Check for chimney blockage and clean if required

Do not attempt to relight until the cause of the emission has been identified and corrected

If necessary seek expert advice.

2.USING THE Appliance FOR THE FIRST TIME

2.1To allow the appliance to settle and fixing glues and paint to fully cure:

Operate the appliance at a low output for first few days

2.2Do not touch the paint during the first period of use.

2.3During this time the appliance may give off some unpleasant odours:

Keep the room well ventilated to avoid a build-up of fumes.

3.RECOMMENDED FUELS

3.1Wood Logs:

Burn only seasoned timber with a moisture content of less than 20%



Wood Length

Appliance

Wood Length

Regency Small

410mm

Regency Medium

480mm

Regency Large

580mm

Dry cut wood for 12 to 18 months before use

Poor quality timber:

Causes low combustion efficiency

Produces harmful condensation

Do not burn construction timber, painted, impregnated

/ treated wood, manufactured board products or pallet wood.

3.2Solid fuel:

• Burn only anthracite or manufactured briquette smokeless fuels listed as suitable for use with open heating appliances

Do not burn bituminous coal, ‘petro-coke’ or other petroleum based fuels as this will invalidate the product guarantee.

3.3Fuel consumption.

As tested at nominal heat output to the requirements of EN 13229: 2001 for intermittent operation:

Description

Fuel Consumption













Kg/hour

Kg/hour





Wood

Briquette







Smokeless fuel









1000

Small Regency

4.4

1.3









1001

Medium Regency

6.8

1.5

1002

Large Regency

N/A

N/A

3.4For advice on suitable solid fuels:*

• Contact your local approved coal merchant

A number of factors can affect the performance of the appliance. See Section 8 for details.

*In the U.K:

Ring the Solid Fuel Association advice line on 0845 601

4406 for details

Visit their web site at www.solidfuel.co.uk

6
