Frigidaire FGB24S5AS, FGB24S5AB Single Oven Models Only, Oven Vent Location, Arranging Oven Racks

Page 10

Single Oven Models Only

Before Setting Oven Controls

Oven Vent Location

The oven is vented through the upper control panel trim and grille or through the bottom grille of the upper control panel. When the oven is on, warm air is released through the vents. This venting is necessary for proper burner operation in the oven and good baking results. DO NOT block the vents. Doing so may cause baking failures, fire or damage to the wall oven.

Arranging Oven Racks

ALWAYS ARRANGE OVEN RACKS WHEN THE OVEN IS COOL (PRIOR TO OPERATING THE OVEN). Always use oven mitts when using the oven.

To remove an oven rack, pull the rack forward until it stops. Lift up front of rack and slide out.

To replace an oven rack, fit the rack onto the guides on the oven walls. Tilt the front of the rack upward and slide the rack back into place.

Single Oven Models

Some models have 2 flat racks. Other models have one flat rack and one offset rack. The rungs on the offset rack are slightly raised from the edges of the rack. This raised part of the rack is designed to allow easy and safe removal of foods from the lower racks of the oven and prevent hands from contacting the hot oven door. Always use the offset rack in the lower position.

Setting Oven Controls

For setting the oven controls, refer to the section on the timer or Electronic Oven Control Guide.

Adjusting Oven Temperature

For instructions on how to adjust the oven temperature refer to Timer Section or Electronic Oven Control Guide.

General Cleaning

To Remove and Replace Oven Door (single Oven Models)

1.Open the door to the fully opened position.

2.Pull up the lock located on each hinge support and engage it in the hook of the hinge lever. You may have to apply a little downward pressure on the door to pull the locks fully over the hooks.

3.Grasp the door by the sides, pull the bottom of the door up and toward you to disengage the hinge supports.

4.Keep pulling the bottom of the door toward you while rotating the top of the door toward the appliance to completely disengage the hinge levers.

5.To reinstall the oven door, reverse steps 1 through 4. Make sure the hinge supports are fully engaged before unlocking the hinge levers.

The door is heavy. For safe, temporary storage, lay the door flat with the inside of the door facing down.

Door Removal

10
