Alcatel F200 TRIO Using Your Phone, Private Phonebook, Troubleshooting, Registration, Safety

4.USING YOUR PHONE

4.1.Make a Call

4.1.1.Preparatory Dialing

Enter the phone number and press T or S (Versatis F250 Only) to dial the number. Press C to clear the entry.

4.1.2. Direct Dialing

Press T or S (Versatis F250 Only) to take the line and enter the phone number.

4.1.3. Dial from Direct Memory Keys

In idle or off hook mode, press and hold 1/2/3 to dial the direct memory number. You have to store number to the related key first. See section 7.4 for reference.

4.1.4. Call from the Redial List

Press E (Versatis F200 Only) or - (Versatis F250 Only) to access the redial list and press +/- to select the desired redial number. Press T or S (Versatis F250 Only) to dial out to the selected redial number.

4.2.Handset Speakerphone (Versatis F250 Only) During a call, you can press S to alternate between handsfree and normal handset use.

5.PRIVATE PHONEBOOK

Your phone can store up to 50 private phonebook entries with names and numbers. Each phonebook entry can have a maximum of 20 digits for the phone number and 12 characters for the name. You can also select different ringtones for your phonebook entries. Phonebook entries are stored alphabetically by name.

7.2. Set the Ringer Volume

111Press M and +/- to select HS SETTINGS.

222Press M and +/- to select RING SETUP.

333Press M and +/- to select RING VOLUME.

444Press M and +/- to select the desired ringer volume (a total of 6 ringer volume levels including VOLUME OFF).

Note: The respective ringer volume will be played during your selection.

If VOLUME OFF is selected, n icon will display.

555Press M to confirm.

7.3.Adjust Earpiece and Handsfree (Versatis F250 Only) Volume

There are 5 levels (VOLUME 1 to VOLUME 5) to choose from for each of earpiece and handsfree (Versatis F250 Only) volume.

During a call:

Press +/- to select volume 1-5. The current setting is shown. When you end the call, the setting will remain at the last selected level.

7.4. Store Direct Memory Access Number

You can store three direct access numbers into digit KEY 1, KEY 2 and KEY 3, which will be convenient for you to dial to these numbers directly.

111Press M and +/- to select HS SETTINGS.

222Press M and +/- to select DIRECT MEM.

333Press M and +/- to select any one from KEY 1, KEY 2 and KEY 3.

444Press M and then enter the number you would like to store, or edit the number existed before.

555Press M to confirm.

Note: Press and hold 1, 2 or 3 to call the stored number.

10. TROUBLESHOOTING

If you have difficulty with your phone, please try the suggestions listed below.

As a general rule, if a problem occurs, remove the batteries from all the handsets in your installation for about 1 minute, then disconnect and reconnect the power supply to the base and reinstall the handset batteries.

Problem	Cause		Solutions
No dialing	a.	The connection	a.	Check the
tone when		cord of the base		connections. Unplug
pressing		station is not		and plug back in the
T key		plugged in.		mains. Check that the
				telephone line cord
				has been plugged into
				the base station and
				the phone socket.
	b. The adapter cord		b. Check the base
		is not plugged in		station plug and the
		correctly in the		220V plug (remove
		base station.		and plug-in).
	c.	The line is busy, as	c.	Wait until the line is
		another handset is		unoccupied.
		used.
	d.	Wrong connection	d.	Use the original
		cord.		connection cord.
"OUT OF	a.	Base station out of	a.	Reduce the range.
RANGE" is		range.
displayed.	b.	Base station not	b.	Connect base station
		connected to		to mains.
		mains.
The call	Service not activated		Check your Subscription
does not	or wrong operator.		with network.
work.
No display.	Empty battery.		Recharge battery.

The store where you bought your telephone can also provide you with information and after-sales support.

5.1.Add a New Phonebook Entry In idle:

111 Press P to access the phonebook.

OR

Press M and +/- to select PHONEBOOK main menu item and then press M to access the phonebook.

222 Press M to select ADD.

333 Press M to enter the name.

444 Press M to enter the number.

555 Press M and +/- to select the desired ringtone for your phonebook entry.

666 Press M to store the phonebook entry.

5.2.Call from the Phonebook

In idle:

111Press P to access the phonebook.

OR

Press M and +/- to select PHONEBOOK main menu item

and then press M to access the phonebook.

222Press T or S (Versatis F250 Only) to dial out to the selected phonebook entry.

6.CALLER DISPLAY (NETWORK DEPENDENT)

This feature is available if you have subscribed the Caller Line Identification service with your telephone service provider. Your phone can store up to 20 received calls with date/time information in the Call List. The number will be shown on the LCD when the phone is ringing. If the number matches with one of the entries in your Private Phonebook, the caller’s name stored in the private phonebook will be displayed alternatively with the number. The handset will ring with the melody associated with that phonebook entry.

If the caller number is disabled to send caller information, “WITHHELD” will display.

If the caller number is not provided, “OUT OF AREA” will display. In standby, if three unanswered calls are received, “3 NEW CALLS” will be displayed.

8.REGISTRATION

Your handset and base station is pre-registered. Up to five handsets can be registered to a single base station.

If for some reason, the handset is not registered to the base station (h flashes even when the handset is near the base station), register your handset according to the following procedure.

111Press and hold A on the base station for about five seconds,

the base station is entered into registration mode.

222 Press M and +/- to select REGISTRATION.

333 Press M and you are requested to enter the 4-digit system PIN (default PIN is 0000).

444Enter the 4-digit system PIN.

555Press M to confirm.

If the handset registration is successful, you will hear a confirmation tone and the h will stop flashing. The handset will automatically be allocated the next available handset number. This handset number is shown in the handset display in standby mode. If the handset registration is unsuccessful, the h will still flash.

11. SAFETY

In the event of an electrical hazard, the mains adapter acts as 230V power isolating device. It should therefore, as a precaution, be installed close to the appliance and be easily accessible. To disconnect the device from the primary power source, the mains adapter must be removed from the 230V AC/50 Hz socket.

If the mains adapter fails, it must be replaced by an identical model.

If not connected to the mains power or if there is a mains power failure, telephones that use cordless handsets will not work.

You will then be unable to make or receive calls in the event of an emergency.

This is why we recommend that you also keep a conventional telephone – one that doesn’t require a power supply – as a backup.

!Do not use your telephone to notify a gas leak when standing in the vicinity of the leak.

It is recommended that you avoid using this device during electrical storms.

Do not attempt to open the batteries, as they contain chemical substances. In the event of leakage, avoid contact with the skin, eyes, nose and mouth. In the event of contact, rinse the affected part for about twenty minutes with running water and seek urgent medical attention. Clean the product with absorbent paper or a dry cloth and contact your reseller for replacement batteries.

ATLINKS hereby declares that the following models conform to the essential requirements and other applicable provisions of European directive 1999/5/EC.

Versatis F200/Versatis F200 Duo/Trio

Versatis F250/Versatis F250 Duo/Trio

6.1. View the Call List

All received calls are saved in Call List with the latest call putting at the top of the list. When the call list is full, the oldest call will be replaced by a new call. The unanswered call which has not been read is marked with a s at the centre of the bottom line of the display.

111Press + to access the call list.

OR

Press M and +/- to select CALL LIST.

222 Press +/- to select the desired entry.

333 Press # to view the caller’s number if applicable.

6.2.Call from the Call List In idle:

111 Press + to access the call list.

OR

Press M and +/- to select CALL LIST.

222 Press T or S (Versatis F250 Only) to dial out to the selected phonebook entry.

7.PHONE SETTINGS

7.1.Set the Ringer Melody for Internal/External Calls 111 Press M and +/- to select HS SETTINGS.

222 Press M and +/- to select RING SETUP.

333 Press M and +/- to select INT RING or EXT RING.

444 Press M and +/- to select the desired ringer melody from the melody list.

Note: The respective ringer melody will be played while browsing the melody list.

555 Press M to confirm.

9.TECHNICAL DETAILS

Free Field Range	Up to 300 metres*
Indoor Range	Up to 50 metres*
Handset Battery Life	10 hours talk time**
(average values)	100 hours standby**
Number of Handsets	Up to 5
Intercom Mode	Yes
Three-Way Conference	Yes
(1 outside correspondent +
2 internal correspondents)
Electrical Connection/Base	Base main adaptor:
Mains Adaptor/Charger	Model No.: S004LV0600030
	Input: 100-240 V/50-60 Hz/0.15 A
	Output: 6 V DC/300 mA
	Charger adaptor:
	Model No.: S004LV0600030
	Input: 100-240 V/50-60 Hz/0.15 A
	Output: 6 V DC/300 mA
	Only use the adaptors supplied with
	the telephone
	Single-phase AC, excluding
	IT installations defined by the
	EN60950 standard.
	Caution: The network voltage is
	classified as a hazard by the criteria
	of this standard.
Telephone Connection	Appliance designed for
	connection to a TNV3 class
	(telecommunications network
	voltage) analogue telephone line as
	defined by the EN60950 standard.
Batteries	AAA – 1.2 V – 400 mA
	Only use the batteries supplied with
	the telephone.
	Use any other type of battery
	presents a risk of explosion.
	Used batteries must be disposed
	of in compliance with current
	environmental protection
	regulations.
Operating Temperature	From 5°C to 40°C

*Values may vary according to environment.

**Depending on initial battery charge.

12. ENVIRONMENT

This symbol means that your inoperative electronic

appliance must be collected separately and not mixed with the household waste. The European Union has implemented a specific collection and recycling system for which producers are responsible.

This appliance has been designed and manufactured with high quality materials and components that can be recycled and reused. Electrical and electronic appliances are liable to contain parts that are necessary in order for the system to work properly but which can become a health and environmental hazard if they are not handled or disposed of in the proper way. Consequently, please do not throw out your inoperative appliance with the household waste.

If you are the owner of the appliance, you must deposit it at the appropriate local collection point or leave it with the vendor when buying a new appliance.

-If you are a professional user, please follow your supplier's instructions.

-If the appliance is rented to you or left in your care, please contact your service provider.

Keen to preserve the environment, ATLINKS has equipped this appliance with a switching power supply, offering better energy efficiency. The advantages include not only very low electricity consumption, but also a more compact format than the conventional power supply units used by the previous range.

The used batteries from your telephone (if it has batteries) must be disposed of in compliance with current environmental protection regulations. Comply with your local regulations. Return your batteries to your reseller or dispose of them at an approved recycling centre.

Help us protect the environment in which we live!
