C L E A N I N G / M A I N T E N A N C E
T R O U B L E S H O O T I N G
WA R R A N T Y I N F O R M AT I O N
Figure 2 |
|
|
| J |
|
| K | |
|
|
| E |
|
|
|
| |
|
|
|
|
|
|
|
| L |
| C |
| D |
|
|
|
| M |
|
|
|
|
|
|
| ||
B |
|
|
|
|
|
|
|
|
A |
|
|
|
|
|
|
|
|
F |
|
|
|
| E |
|
|
|
|
|
|
| G |
|
|
| |
H |
|
|
| I |
|
|
| |
|
|
|
|
|
|
| ||
A. | Power Button ( | ) | H. | Filter Check |
| |||
B. | Speed Controls |
|
| Indicator ( | ) | |||
| ( | / | ) |
|
| I. | Speed Setting | |
C. | Timer Button ( | ) |
| Indicator ( | ) | |||
D. | Ionizer Button ( | ) | J. | Filtered Air Outlet | ||||
E. | LCD Display |
|
|
| (not shown) |
| ||
F. | Timer Icon/ |
|
| K. | ||||
| Indicator ( | ) |
|
| Filters |
| ||
G. | Ionizer Icon/ |
|
| L. | Washable Foam | |||
| Indicator ( | ) |
| M. |
| |||
|
|
|
|
|
| Air Inlet Grill |
| |
CLEANING AND MAINTENANCE
Cleaning the unit:
1.Turn off and unplug the air cleaner.
2.The outside of the unit can be cleaned with a soft, clean dampened cloth.
3.The air inlet grill (see figure 2) can be cleaned with a soft, clean damp cloth.
4.The filtered air outlet can be cleaned of dust with a small soft brush.
5.If you wish to clean the inside of the air purifier, please only use a dry, soft cloth to wipe it down. DO NOT WASH FILTERS.
6.NEVER use detergents, gasoline, glass cleaner, furniture polish, paint thinner or other household
solvents to clean any part of the air cleaner. WARNING: Do not allow moisture to come in contact with the main housing of the air purifier.
FILTER REPLACEMENT INSTRUCTIONS
1.On average, HEPA filters need to be replaced every
2.Turn off and unplug the air
purifier before attempting |
| |
to replace the filters. |
| |
3. Remove each of the filters |
| |
from the unit by pulling |
| |
them gently towards you. | Figure 3 | |
4. Discard the old HEPA | ||
| ||
filters. DO NOT attempt to |
| |
clean them. |
| |
5. Remove protective plastic |
| |
bags and install new |
| |
HAPF350 |
| |
HEPA filters into the unit. |
| |
NOTE: Use a hang tab and | Figure 4 | |
filter clips to ensure the filter | ||
| ||
attaches properly: |
|
•Make sure the hang tab is securely in place. Align the clip on the top of the filter with the rails on the inside of the unit. Gently slide the filter onto the rail (see Figures 3 and 4).
•Place air inlet grill back onto unit securely.
6.Reset the Filter Check Indicator by pressing the Power button (
) for 3 seconds.
NOTE: Every time you power on the air cleaner, the Filter Check Indicator icon (
) will blink 3 times on the LCD display. This routine test checks the current condition of the filters. If filters are in good condition, the icon will disappear. If not, the icon will remain lit until filters have been replaced and Filter Check Indicator (
) has been reset (see instructions above).
Replacement filters can be purchased at online at www.bionaire.com or by calling
TIPS AND TROUBLESHOOTING
Problem | Solution |
•Unit will not operate ✔ Make sure the unit is plugged in and outlet is energized.
✔Make sure unit turned ON.
• Decreased air flow | ✔ Make sure nothing is blocking air inlet and filtered air outlets. |
✔Remove all plastic bags from filters.
✔Check condition of filters and replace if necessary.
•
dirty | materials. This is NOT dirt; in fact, these particles are the essential elements |
| for this filter's effectiveness in fighting airborne bacteria and germs. |
|
|
• Excessive noise | ✔ Remove plastic bags from filters. |
✔Make sure parts are firmly positioned in place.
•The filter check indicator ✔ Check condition of the filters and replace if necessary.
will not reset | ✔ Press and hold down the Power button ( ) for 3 seconds. The Filter Check |
| Indicator icon on the display screen should disappear. |
LEARNING MORE
For a wealth of information about your air cleaner and other Bionaire® products, visit our website at www.bionaire.com or call
3 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of three years from the date of purchase, this product will be free from defects in material and workmanship. JCS, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period. Replacement will be made with a new or remanufactured product or component. If the product is no longer available, replacement may be made with a similar product of equal or greater value. This is your exclusive warranty. Do NOT attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service centers, or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on JCS’s Liability?
JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for a particular purpose is limited in duration to the duration of the above warranty.
JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract, fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province, state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service, please call
In Canada
If you have any question regarding this warranty or would like to obtain warranty service, please call
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions located in Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing business as Jarden Consumer Solutions, located at 20 B Hereford Street, Brampton, Ontario L6Y OM1. If you have any
pure indoor living
AIR CLEANER
WITH
SILVER TECHNOLOGY
MODEL: BAP9700S
Instruction Guide
Filters can be purchased online at www.bionaire.com, or by calling
| Air Purifier Model # |
| Filter Quantity Needed | Filter # | Filter Description |
|
|
|
|
|
|
| BAP9700S |
| 2 | HAPF350 (K filter) |
|
|
|
|
|
|
|
1 |
|
|
| ||
© 2010 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All Rights Reserved. Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.
141378/9100040004478 | Printed In China | |
|
|
|
other problem or claim in connection with this product, please write our Consumer Service Department. PLEASE DO
NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
Read instructions before operating. Retain for future reference.
Questions? Comments? Call
or visit our website at www.bionaire.com.
