Clearing Clogs

Low suction or poor pickup may be due to a clog in the vacuum cleaner. If you notice a change in the sound of the motor or a reduction in the spinning action, check for clogs.

1.Unplug cleaner from electrical outlet.

2.Empty Dirt Container.

3.Check Upper Tank for build up or clogs.

4.Remove the Upper Tank and check the suction inlet for a clog.

5.Grasp the Hose Grip and lift to separate from the suction opening. Check for a clog in the Base or the Hose.

For Models with the Twist 'n Snap Hose Release the hose from the vacuum by turning to

the left. Straighten the hose and unclog with a long, narrow object.

6.If the clog persists, follow the instructions for Checking the Rotating Brush on page 11 and inspect the Air Passageway for obstructions.

Thermal Protector

Suction

Opening

Air Passageway

Suction Inlet

An internal thermal protector has been designed into your cleaner to protect it from overheating.

When the thermal protector activates, the main vacuum motor will stop operating. If this happens, proceed as follows:

1.Turn the cleaner OFF (O) and unplug from electrical outlet.

2.Check the Upper Tank area, Pre-Motor Filter and Post-Motor Filter for dirt accumulation.

3.Refer to the "Clearing Clogs" section.

4.When the motor cools for approximately 30 minutes, the thermal protector automatically resets and cleaning may continue. If the thermal protector continues to activate after following the above steps, your cleaner may need servicing. Call BISSELL Consumer Services, or visit the website.

Note: The thermal protector controls the main vacuum motor only, not the brush motor. If the thermal protector activates, the brush will continue to operate normally; however, there will be no suction.

ug603-5540_3750_1004.indd 13

Caution:

To reduce the risk of injury from moving parts, turn off vacuum cleaner and disconnect Power Plug from electrical outlet.

13
