Bogen AE-112s2 dimensions AE-12s2SUBWOOFER, Not To Scale, ZAE-12, Section A-A, A Front View

SECTION A-A

22.563

[573.10]

44.750 [1136.65]

30.000

[762.00]

A

FRONT VIEW

AE-12s2 SUBWOOFER

14.000 [355.60]

15.000

[381.00]

A
NUTPLATE	CONNECTOR PANEL
2 EACH SIDE

NOTE: DIMENSIONS ARE IN INCHES & [MILLIMETERS]

INFORMATION CONTAINED IN THIS DOCUMENT IS THE SOLE PROPERTY

OF APOGEE SOUND

INTERNATIONAL, LLC. REPRODUCTION OF ALL OR ANY PART OF THIS DOCUMENT WITHOUT WRITTEN CONSENT FROM APOGEE SOUND INTERNATIONAL, LLC. IS PROHIBITED.

NOT TO SCALE

SCALE	1/5	DRAWN	WWE	9/1/99
		REVISED
PRODUCT
	NUMBER:	SIZE	DRAWING N0.
100-8500		D	ZAE-12

REVISION

A

AE12s2 SUBWOOFER
