Systems SE88 Series Panic Transmitters
SE88 Series Panic Transmitters
▶ Supervision
▶ Manual duress alarm ▶ Test mode
▶ Low battery indication ▶ Water resistant
With the appropriate hardware accessory, an SE88 Series Panic Transmitter model can be worn like a watch, around the neck like a pendant, or mounted on a stationary location with a mounting bracket. During an alarm, the transmitter sends the person’s identity and location to the central console at the security office. It is ideal for use in elder care or assisted living facilities that require immediate emergency notification.
System Overview
During an emergency, the person presses and holds the alarm button to produce an alarm. Generally the system sounders, strobes, or sirens activate within two seconds.
The alarm signal transmits to the receivers which relay the alarm signal to the transponder and to the central console.
The central console shows the person’s location on a map, along with a photograph, name, and vital information such as a medical condition or disability.
Functions
Supervision
The transmitter can send a tracking signal to the central console every 32 seconds or 65 minutes depending on the transmitter model. The tracking signal updates the person’s location. The central console can also use the tracking signal to alert staff if residents or items move away from a defined area.
Manual Duress Alarm
Press the large button on the transmitter to send an alarm. During the alarm, the transmitter automatically continues to transmit every seven seconds, providing the most current location information.
Test Mode
The SE88‑30S‑304 automatically tests itself every
30 seconds. The SE88‑60M‑304 automatically tests itself every 60 minutes. A user (subscriber) can also press the small button to perform a manual test anywhere in the protected area. When the user sees an indoor receiver or an outdoor strobe, the user can press the manual test button to perform a test. A small green light flashes on an indoor receiver or the strobe flashes during a successful test. The visual indicators (flashing green light or strobe light) are absent when the test fails. The central console
