PHOTOMETRICS [Complete IES files available at www.cooperlighting.com]

A B C D

TMU17MXX3VF

175-Watt MH

14,000-Lumen Clear Lamp

Type III Vertical

Flat Glass

A B

C

D E

A B C D

TMU17MXXASF

175-Watt MH

14,000-Lumen Clear Lamp

Area Square

Flat Glass

A B C D E

A B C D E

TMU25MXXSLF

250-Watt MH

20,500-Lumen Clear Lamp

Spill Light Eliminator

Flat Glass

A B C D E

A

B

C D E

TMU40MXX3SF

400-Watt MH

36,000-Lumen Clear Lamp

Type III Segmented

Flat Glass

A

B C D

E

Fo o t c a n d l e Ta b l e

Select mounting height and read across for footcandle values of each isofootcandle line. Distance in units of mounting height.

Mounting

Footcandle Values for





Height

Isofootcandle Lines







A

B

C

D

E

175W [3V/AS]









15'

1.70

0.85

0.34

0.17

--

20'

1.00

0.50

0.20

0.10

--

25'

0.64

0.32

0.13

0.06

--

250W [SL]/400W [3S]







20'

2.00

1.00

0.50

0.20

0.10

25'

1.28

0.64

0.32

0.13

0.06

30'

0.88

0.44

0.22

0.09

0.04

Fo o t c a n d l e Ta b l e

Select mounting height and read across for footcandle values of each isofootcandle line. Distance in units of mounting height.

Mounting Footcandle Values for





Height

Isofootcandle Lines







A

B

C

D

E

400W [3V/4V/5S/AR]







20'

3.00

1.50

0.75

0.30

0.15

25'

2.00

1.00

0.50

0.20

0.10

30'

1.38

0.69

0.34

0.13

0.06

TMU40MXX3VS

TMU40MXX4VS

TMU40MXX5SF

400-Watt MH

400-Watt MH

400-Watt MH

36,000-Lumen Clear Lamp

36,000-Lumen Clear Lamp

36,000-Lumen Clear Lamp

Type III Vertical

Type IV Automotive Perimeter

Type V Segmented

Sag Glass

Sag Glass

Flat Glass

TMU40MXXARS

400-Watt MH

36,000-Lumen Clear Lamp

Area Round

Sag Glass

MOUNTING CONFIGURATIONS

Wall Mount















Arm Mount Single

Arm Mount 2 @ 180°

Arm Mount 2 @ 90°

Arm Mount 3 @ 120°

Arm Mount 3 @ 90°

Arm Mount 4 @ 90°



















E.P.A.





E.P.A.



E.P.A.



E.P.A.



E.P.A.



E.P.A.





















TMU





TMU



TMU



TMU



TMU



TMU





















Recessed Door

1.22

Recessed Door

2.44

Recessed Door

2.44

Recessed Door

3.23

Recessed Door

3.23

Recessed Door

3.63



















Deep Door

1.45

Deep Door

2.90

Deep Door

2.90

Deep Door

3.92

Deep Door

3.92

Deep Door

4.43









































































































Specifications and Dimensions subject to change without notice.

TMU_ADH081549

Streetworks • Customer First Center • 1121 Highway 74 South • Peachtree City, GA 30269 • TEL 770.486.4800 • FAX 770.486.4801

08/05/2008 2:32:09 PM

Page 3
