Craftsman 917.385124 owner manual BRIGGS & STRATTON 4-CYCLE ENGINE, MODEL NUMBER 10T802-3708-EA

BRIGGS & STRATTON 4-CYCLE ENGINE MODEL NUMBER 10T802-3708-EA

KEY PART

NO. NO. DESCRIPTION

1 699650 Cylinder Assembly

2399269 Bushing/Seal Kit (PTO Side)

3299819s • Seal-Oil (PTO Side)

4698691 Sump-Engine

5790169 Head-Cylinder

7698717 • Gasket-Cylinder Head

8791781 Breather (Includes Gasket)

9695890 • Gasket-Breather

10691666 Screw (Breather Assembly)

11691245 Tube-Breather

12692218 • Gasket-Crankcase

13691640 Screw (Cylinder Head)

15691680 Plug-Oil Drain

16691472 Crankshaft

2O 391483s • Seal-Oil (Magneto Side)

22692551 Screw (Engine Sump)

23692009 Flywheel

24222698s Key-Flywheel

25790908 Piston Assembly (Standard)

25792532 Piston Assembly (.020" O.S.)

26790909 Ring Set (Standard)

26792533 Ring Set (.020" O.S.)

27691588 Lock-Piston Pin

28699659 Pin-Piston (Standard)

29699654 Rod-Connecting

32691664 Screw (Connecting Rod)

33296676 Valve-Exhaust

34296677 Valve-Intake

35690520 Spring-Valve (Intake)

36690520 Spring-Valve (Exhaust)

37697403 Guard-Flywheel (Carb. Side)

37A 691209 Guard-Flywheel (Muffler Side)

40692194 Retainer-Valve

43 697799 Slinger-Governor/Oil

45 691762 Tappet-Valve

KEY

NO.

46

48

5O

51

54

55

58

60

65

73

78

90

97

130

163

180

190

190A

2O2

209

222

227

287

3OO

304

3O5

306

307

332

333

334

337

356

358

363

PART
NO.	DESCRIPTION
691998	Gear-Cam
793347	Short Block
792388	Manifold-Intake
792389	• Gasket-Intake
691111	Screw	(Intake Manifold)
692144	Housing-Rewind		Starter
697316	Rope-Starter
691915	Grip-Starter Rope
690837	Screw	(Rewind	Starter)
699850	Screen-Rotating
692198	Screw	(Flywheel	Guard)
794231	Carburetor
697414	Shaft-Throttle
691190	Valve-Throttle
271139s • Gasket-Air Cleaner
494406	Tank-Fuel
692198	Screw	(Fuel Tank)
691640	Screw	(Fuel Tank)
698835	Link-Mechanical		Governor
698726	Spring-Governor
698725	Bracket-Control
697402	Lever-Governor		Control
691002	Screw	(Dipstick	Tube)
394569s	Muffler
697411	Blower	Housing
692198	Screw	(Blower Housing)
690400	Shield-Cylinder
690345	Screw	(Cylinder	Shield)
690662	Nut (Flywheel)
792395	Armature-Magneto
691061	Screw	(Magneto	Armature)
802592s	Plug-Spark
692390	Wire-Stop
794209	Gasket	Set-Engine
19069	Flywheel Puller

36
