Ex2900 / Ex3200 ATTACHMENTS

BS60 Box Scraper

Heavy-duty A-frame is constructed from ½” thick steel for greater control and strength during grading and backfill operations. The A-frame and box are attached with a 5/8” thick steel frame making the scraper extremely rigid for uncompromising control. The 4” x 4-1/2” cross beam is the main structural component. The box is made out of ¼” thick steel with ¼” thick reinforcement brackets at each corner. The 5/8” hardened steel ripping shanks with replaceable tips allow them to dig into the toughest soil conditions. Reversible hardened blades give longer life.

FB72 72” Dozerblade

Heavy-duty moldboard allows for longer life in all working conditions. The ¼” high-carbon reversible cutting edge gives the blade longer life. Hydraulic power angle provides smooth, precise control. Power down pressure allows the blade to dig into the ground to loosen packed snow or hard dirt. QuickAttach™ hitch makes attaching and detaching the blade easy and fast.

RC60 60” Rotary Cutter

Deck housing is constructed from 10-gauge steel and reinforced with a 10- gauge plate under the gearbox assembly. Features cutting height adjustment from 1” to 9-1/4” with oval stump jumper. Heavy-duty drive line with shear bolt protection transfers power smoothly and protects the valuable components of the tractor. Hardened spring steel blades are mounted on high-carbon steel rotors. Floating top link allows for rotary cutter to follow the contour of the land for clean and even cutting. Laminated tail wheel is puncture resistant and long wearing in harsh brush-cutting conditions.

HC300 Hard Cab Assembly

The steel-constructed roof is lined with a fabric headliner to help reduce drivetrain noise and increase operator comfort and overall appearance. Steel doors with fixed glass allow for a tighter seal over fabric door construction and provide better climate control. Front windshield with tempered glass is clearer and more durable, and provides better performance from the wiper assembly with less window flex. Standard front windshield wiper with single speed provides for clearer sight lines in adverse conditions. Soft rear removable panel makes it a snap to open the cab in warmer conditions.

Page 2 Page 3
Page 3
Image 3
Cub Cadet EX2900, EX3200 manual BS60 Box Scraper, FB72 72 Dozerblade, RC60 60 Rotary Cutter, HC300 Hard Cab Assembly
Page 2 Page 3

EX2900, EX3200 specifications

The Cub Cadet EX2900 and EX3200 models represent a top tier of sub-compact tractors, designed to meet the diverse needs of homeowners and landscape professionals. Renowned for their reliability and performance, these tractors are equipped with robust features and advanced technologies.

At the heart of the EX2900 and EX3200 is a powerful, fuel-efficient engine. The EX2900 boasts a 29 horsepower engine, while the EX3200 takes it up a notch with a 32 horsepower variant. Both engines feature a liquid cooling system, ensuring optimal performance even under heavy loads. This added power allows for efficient operation of various implements such as loaders, mowers, and tillers, making them ideal for a range of tasks from mowing lawns to landscaping and agricultural duties.

One of the standout characteristics of these models is their hydrostatic transmission. This allows for smooth, effortless speed control and direction changes without the need for manual gear shifting. Operators appreciate the ease of use, especially when navigating tight spaces or performing multiple tasks in quick succession.

Comfort and convenience are also prominent in the design of the EX2900 and EX3200. The spacious operator station features an ergonomic seat with ample legroom, providing comfort during long hours of operation. Easy-to-reach controls and a dashboard with clear indicators enhance usability, making tasks simpler and more efficient.

In addition to power and comfort, these tractors emphasize versatility. A quick-attach loader system allows users to switch out attachments swiftly, adapting to a variety of chores. The three-point hitch increases compatibility with various implements, giving owners the flexibility to tackle different jobs with ease.

Cub Cadet has integrated advanced technology into the EX2900 and EX3200 models to enhance performance further. A 12-volt electrical system provides reliable starting power, while the LED headlights improve visibility during early morning or evening operations. Safety features such as an ROPS (Roll-Over Protective Structure) add an additional layer of protection for operators.

Overall, the Cub Cadet EX2900 and EX3200 tractors combine power, comfort, and versatility, making them ideal choices for homeowners and professionals alike. With their dependable performance and user-friendly features, these models are built to tackle everything from simple yard maintenance to more demanding agricultural tasks, delivering quality and reliability in every job.
