19.8" x 14.2" x 12.9" 21.2 lb
5.6" x 6.3" x 5.6"
0.7 lb

Epson MovieMate72

SPECIFICATIONS

PROJECTION SYSTEM

3LCD technology 3-chip optical engine Poly-silicon TFT active matrix

RESOLUTION

Native 720p (1280 x 720)

ASPECT RATIO

Native 16:9 widescreen (4:3 resize)

Compatible with 4:3 and 2.35:1 video formats with Normal, Full or Zoom Modes

LUMENS*

1200 lumens color light output

1200 lumens white light output (ISO 21118 standard, in Dynamic Mode)

CONTRAST RATIO

1000:1





5 COLOR MODES

Dynamic, Livingroom, Theater, Theater Black,



Game





ZOOM RATIO

Optical 1.5x





PROJECTION LENS

F-number: 1.7 – 2.1, 13.7 – 20.5 mm



focal length

WIDESCREEN IMAGE SIZE (PROJECTED DISTANCE)

30" – 150" wide: 2.4' – 12.2' (16:9 image)

KEYSTONE CORRECTION

Vertical +/-15 degrees

LENS SHIFT (OPTICAL IMAGE ADJUSTMENT)

Vertical: 50% maximum upward/downward

Horizontal: 25% maximum left/right

Quick image adjustment dials

BUILT-IN SPEAKERS

Integrated 4 x 5 W stereo speakers

DVD UNIT

Digital Direct Progressive Scan system

Audio

DTS Digital Surround and Dolby Digital

Media and format

DVD Video, DVD-R/RW, DVD+ R/RW,



DVD-ROM, DVD Audio, CD-R/RW, CD-ROM,



DVD-VR (without CPRM) Video CD, Super



Video CD, Audio CD, MP3 (CD/DVD), WMA



(CD/DVD), JPEG, DivX® (CD/DVD), DivX Ultra



(CD/DVD), Dual Disk





FAN NOISE

28 dB





LAMP

140 W UHE (Ultra High Efficiency)

LAMP LIFE**

Up to 3000 hours in Theater Black Mode

DIMENSIONS (W x D x H)

12.9" x 10.2" x 6.9"





WEIGHT

15.2 lb

VIDEO INPUT SIGNAL

DVD Region Code 1

NTSC, NTSC4.43, PAL, M-PAL, N-PAL, PAL60, SECAM,

HDTV (720P, 1080i), SDTV (525i / 525p / 625i / 625p)

HD-DVD and Blu-ray (external source only)

TERMINAL INPUTS

1 RCA (composite)

1 Mini Din (S-video)

2 RCA (audio L/R) stereo

1 VGA (analog RGB/component video) D-sub 15 pin Analog RGB to component video adapter included HDMI 1.2a

USB

TERMINAL OUTPUTS

1 headphone stereo jack

1 optical audio out

1 RCA (for external subwoofer)

COMPUTER COMPATIBILITY

SXGA

XGA

SVGA

VGA

Mac

WXGA

PARENTAL CONTROL



Restricted access

Prevents your child from viewing inappropriate



DVDs

Power button lock

Hinders MovieMate from being turned on



without parental supervision





PACKAGING DIMENSIONS (W x D x H)

Epson MovieMate 72

Dimensions

Weight

Replacement lamp – Single unit

Dimensions

Weight

Replacement lamp – Master carton

Dimensions

28.4" x 13.1" x 6.8"

Weight

8.8 lb

Units per master carton

10

PRODUCT/ACCESSORY PART NUMBERS



Epson MovieMate 72



Product code

V11H257220

UPC code

0-10343-86647-8

Replacement lamp



Product code

V13H010L44

UPC code

0-10343-86649-2

Air filter



Product code

V13H134A15

UPC code

0-10343-86652-2

Rolling carrying case



Product code

V12H001K59

UPC code

0-10343-86723-9

WARRANTY

Includes two years of toll-free, priority technical support, plus Epson’s two-year limited warranty and a 90-day limited lamp warranty

*Light output varies depending on modes (color and white light output). White light output measured using ISO 21118 standard.

**Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.

Epson America, Inc.

3840 Kilroy Airport Way, Long Beach, CA 90806

Epson Canada, Ltd.

3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5

Specifications and terms subject to change without notice. Epson is a registered trademark and Epson Exceed Your Vision is a registered logomark of Seiko Epson Corporation. Epson MovieMate is a trademark of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. Copyright 2009 Epson America, Inc. CPD-30703 5/09
