Mini DisplayPort Male to VGA Male Cable

The Extron® Mini DP-VGA/6is a six-foot long cable with a male Mini DP connector on one end and a male VGA cable connector on the other end.

The Mini DP to VGA cable offers interconnectability between Mini DisplayPort sources and all VGA devices. In addition, it offers the following features:

•DisplayPort 1.1 compliance

•Supports resolutions up to 1920 x 1200 at 60 Hz

•Passes EDID from a VGA display to a Mini DP source

Mini DP-VGA/6

26-672-06

Laptop with Mini
DisplayPort Output	6' Mini DP to VGA Cable	Projector w/VGA Input
Source			Sink

This powered cable must be used directly at the Mini DP source; it is not intended to be used at a Mini DisplayPort video display. Do not use additional cables or adapters between the source output and the male end of the Mini DP cable.

The cable is unidirectional and is not intended to convert a VGA source to output a Mini DisplayPort signal.

Mini DisplayPort Male to DVI-D Male Cable

The Extron® Mini DP-DVID/6is a six-foot long cable with a male Mini DP connector on one end and a male DVI-D cable connector on the other end.

The Mini DP to DVI-D cable offers interconnectability between Mini DP sources and all DVI devices. In addition, it offers the following features:

•DisplayPort 1.1 compliance

•High-bandwidth Digital Content Protection (HDCP) compliance

•Supports resolutions up to 1920 x 1200 at 60 Hz

•Passes EDID from a DVI display to a Mini DP source

•Gold plating on all contact surfaces for high performance and reliability

Mini DP-DVID/6

26-673-06

Laptop with Mini
DisplayPort Output		Projector w/DVI Input
Source	6' Mini DP to DVI-D Cable		Sink

This powered cable must be used directly at the Mini DP source; it is not intended to be used at a Mini DisplayPort video display. Do not use additional cables or adapters between the source output and the male end of the Mini DP cable.

The cable is unidirectional and is not intended to convert a DVI source to output a Mini DisplayPort signal.
