Technical specifications



























SCO500B

Operating Voltage:

Two 1.5V AA Batteries



Listing:

ETL to UL 217 and 2034 standards





















Humidity Range:

10% - 95% relative humidity (RH)



Alarm Weight:

8.4 oz.







































Smoke Sensor:

Photoelectric



Individual Carton Weight:

0.66 lbs.





























CO Sensor:

Electrochemical



Master Pack Weight:

8.4 lbs.





























Wiring:

N/A



Pallet Weight:

794.2 lbs.





























UPC:

0 29054 51306 9



12 of 5:

100 29054 51306 6

























































































Operating Voltage:

Two 1.5V AA Batteries

Listing:

ETL to UL 2034 standard





C0511B



















Humidity Range:

10% - 95% relative humidity (RH)

Alarm Weight:

8.4 oz.

























Smoke Sensor:

N/A

Individual Carton Weight:

0.66 lbs.



























CO Sensor:

Electrochemical

Master Pack Weight:

8.4 lbs.



























Wiring:

N/A

Pallet Weight:

794.2 lbs.



























UPC:

0 29054 00291 4

I 2 of 5:

100 29054 00291 1

























































Operating Voltage: Two 1.5V AA BatteriesListing:ETL to UL 217 standard

SA511B













Humidity Range:

10% - 90% relative humidity (RH)

Alarm Weight:

8.3 oz.























Smoke Sensor:

Photoelectric

Individual Carton Weight:

0.66 lbs.



















CO Sensor:

N/A

Master Pack Weight:

8.4 lbs.



















Wiring:

N/A

Pallet Weight:

794.2 lbs.



















UPC:

0 29054 00292 1

I 2 of 5:

100 29054 00292 8













































SA520B

Operating Voltage:

120V AC with battery backup (Two 1.5V AA Batteries)



Listing:



ETL to UL 217 standard





















Wiring:

Quick connect plug with pigtails



Pallet Weight:



882.2 lbs.





Humidity Range:

10% - 90% relative humidity (RH)



Alarm Weight:



9.3 oz.





Smoke Sensor:

Photoelectric



Individual Carton Weight:

.74 lbs.





CO Sensor:

N/A



Master Pack Weight:

9.4 lbs.

























UPC:

0 29054 00205 1





I 2 of 5:



100 29054 00205 3



































Common Technical Specs



Common shipping specs

Individual Carton

Master pack





















All Alarms Respond as One

Cost Effective

Retrofit & Remodel

Solutions

Alarm Dimensions:

5” Dia. X 2” High





Temp Range:

40°F (4°C) to 100°F (38°C)





Audio Alarm:

85 decibel alarm





Operating Frequency:

915 MHz. FCC approved. Complies with Part 15 of the FCC Rules





RF Linking:

Automatic with 65,000 security codes





Alarm Reset:

Automatic when smoke and/or CO clears, depending on model





Test/Silence Feature:

Electronically simulates smoke and/or carbon monoxide condition



(depending on model)





Interconnections:

Up to 18 units, RF or hardwired, with smoke, carbon monoxide,



heat alarms and relays. Maximum 12 smoke alarms





Dimension

5.13”L x 2.38”W x 5.13”H

10.75”L x 7.88”W x 11.06”H







Cube

0.04 ft³

0.54 ft³







Quantity

1

12







PALLET INFORMATION

Cases Per Layer

22





Number of Layers

4





Cases Per Pallet

88





Units Per Pallet

1,056





Cube

54.0 ft³





BRK Brands, Inc,

3901 Liberty Street Road

Aurora, IL 60504-8122

All Alarms Respond as One

Phone: 630-851-7330



Tech Services: 800-323-9005



www.firstalert.com, www.brkelectronics.com



OneLink is a registered trademark of BRK Brands, Inc.



First Alert is a registered trademark of the First Alert



Trust used under license.



©2007 BRK Brands, Inc., a Jarden Corporation company (NYSE:JAH)



CM2830

Page 1
Image 1
First Alert SA520B technical specifications Cost Effective

SA520B specifications

The First Alert SA520B is a cutting-edge smoke and carbon monoxide detector designed to enhance home safety. This device combines advanced technology with user-friendly features, making it an essential addition to any household.

One of the standout features of the SA520B is its dual-sensor technology. This unique system includes both photoelectric and ionization sensors. The photoelectric sensor excels at detecting smoldering fires, which are often characterized by smoke and slow combustion. In contrast, the ionization sensor is highly effective at identifying flaming fires that emit little smoke. By incorporating both types of sensors, the SA520B offers comprehensive protection against a wide range of fire scenarios.

In addition to its dual sensors, the First Alert SA520B utilizes an electrochemical sensor for carbon monoxide detection. This technology is known for its precision and reliability, ensuring that even low levels of carbon monoxide are detected quickly. This is particularly important, as carbon monoxide is a colorless, odorless gas that can be deadly if not appropriately monitored.

Another key characteristic of the SA520B is its easy-to-read digital display, which provides real-time updates on both smoke and carbon monoxide levels. The device features a strong battery backup, ensuring that it remains operational during power outages. The installation process is straightforward, allowing homeowners to mount the unit in appropriate locations with minimal effort.

For added convenience, the First Alert SA520B offers a voice alert feature, which can announce the type of danger detected, whether it be smoke or carbon monoxide. This feature helps users quickly differentiate between potential threats and is especially useful during emergencies.

Furthermore, the SA520B is designed with a sleek and modern aesthetic, allowing it to blend seamlessly into various home decors. The unit also comes with a rechargeable battery option, which reduces the need for constant battery replacements and contributes to environmental sustainability.

Overall, the First Alert SA520B stands out due to its powerful combination of dual-sensor technology, easy installation, digital display, and voice alerts. These features work together to create a dependable and effective safety solution for homes, ensuring peace of mind for families. Investing in the First Alert SA520B means prioritizing safety and preparing for potential fire and carbon monoxide risks in today’s modern living spaces.
