Changing the Filter

Locating the Filters

Your refrigerator is equipped with water filtering system. The water filter system filters all dispensed drinking water, as well as the water used to produce ice.

Water Filter

The water filter is located at the top right side of the fresh food compartment.

Replacing the Water Filter

In general, you should change the water filter every six months to ensure the highest possible water quality. The Water Filter Status light on the user interface prompts you to replace the filter after a standard amount of water (200 gallons/757 liters for PureSource UltraTM) has flowed through the system. The water filter status light on this model is not performance tested or certified

by NSF.

If your refrigerator has not been used for a period of time (during moving for example), change the filter before reinstalling the refrigerator.

Filter Cartridge

Ordering Replacement Filters

To order your replacement filters, please visit our online store at www.frigidaire.com/store, by calling toll-free at 877-808-4195, or by visiting the dealer where you purchased your refrigerator. Frigidaire recommends that you order extra filters when you first install your refrigerator, and that you replace your filters at least once every six months.

Here is the product number to request when ordering:

PureSource UltraTM Water Filter

Part #ULTRAWF

More about your Advanced Water Filter

The PureSource UltraTM ice and water filter system is tested and certified to NSF/ANSI Standards 42 and 53 for the reduction of claims specified on the performance data sheet.

Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Systems certified for cyst reduction may be used on disinfected waters that may contain filterable cysts.

Test & certification results:

•Rated Capacity - 200 gallons/757 liters for

PureSource UltraTM ice and water filter

•Rated service flow - .50 gallons per minute

•Operating Temp.: Min. 33°F, Max. 100°F

•Maximum Rated Pressure - 100 pounds per square inch

•Recommended Minimum Operating Pressure: 30 pounds per square inch

To replace your PureSource UltraTM water filter:

It is not necessary to turn the water supply off to change the filter. Be ready to wipe up any small amounts of water released during the filter replacement.

1Turn Off the ice maker by raising the wire signal arm.

2Remove the filter by pushing on the end/face of the filter.

3Slide the old water filter cartridge straight out of the housing and discard it.

4Unpackage the new filter cartridge. Using the alignment guide, slide it gently into the filter housing until it stops against the snap-in connector at the back of the housing.

5Push firmly until the cartridge snaps into place (you should hear a click as the cartridge engages the snap-in connector).

6Turn On the ice maker by lowering the wire signal arm.

7Press and hold the Water Filter button on the Ice & Water Dispenser control panel for three seconds. When the display changes from Red to Green, the status has been reset.

8After replacing the water filter and in order for the ice maker to work properly, it is necessary to clear air from water filter tubing. Once ice maker begins making ice, allow the bucket to fill completely, then discard the first TWO FULL buckets of ice. It will take at least two days to completely fill the bucket on regular ice making mode or 1½ days on fast ice mode.

242292000 specifications

The Frigidaire 242292000 is a reliable and highly functional refrigerator part, specifically designed to enhance the efficiency and performance of various Frigidaire refrigerator models. This component, commonly known as the ice maker assembly, has become an essential item in the realm of modern home appliances, ensuring that families and individuals have convenient access to ice whenever needed.

One of the main features of the Frigidaire 242292000 is its compatibility with a wide range of refrigerator models. The part can be seamlessly integrated into appliances across multiple lines, making it a versatile choice for users. The ice maker assembly is engineered with durability in mind, utilizing high-quality materials that resist wear and tear over time, ensuring long-lasting performance.

The technology behind the Frigidaire 242292000 includes advanced ice production capabilities. The assembly is designed to produce ice efficiently, with the capacity to generate a significant amount of ice within a short period. This is particularly beneficial for households that frequently host gatherings or for those who enjoy ice-cold beverages. The unit's design promotes quick freezing, allowing for rapid ice production without compromising quality.

Additionally, the Frigidaire 242292000 features easy installation and operation. Users can expect a straightforward replacement process, requiring minimal tools and technical know-how. This accessibility empowers homeowners to manage their appliance maintenance independently, saving time and service costs associated with professional repairs.

Another characteristic worth noting is the energy-efficient design of the ice maker assembly. The Frigidaire 242292000 operates using minimal energy, which contributes to lower utility bills while still providing a consistent supply of ice. This eco-conscious aspect aligns with the growing consumer demand for energy-efficient appliances, making it an attractive option for today's environmentally aware customers.

Overall, the Frigidaire 242292000 offers an impressive combination of reliability, efficiency, and ease of use. Its main features and technologies make it an indispensable component for Frigidaire refrigerators, enhancing the user experience by providing a dependable ice-making solution. Whether for everyday use or special occasions, the Frigidaire 242292000 stands out as a top-tier choice in the world of home appliances.

Frigidaire 242292000 manual Changing the Filter
