HP UT-300 manual DM-III Multitest Power Quality Recorders, RC-120S Remcon Relay Switch

F1 F2 F3 F4

GROUND TEST

DM-III MultiTest

Start

Stop

Test Equipment (Cont.)

DM-III Multitest Power Quality Recorders

Features: • True RMS (TRMS) • Measures

AMPROBE

and records broad spectrum of power quality parameters: AC current, AC voltage to 600V including sags and surges, harmonics (THD and individual up to 49th), active, reactive and apparent power and energy, peak demand, power factor, frequency measurement and phase sequence • Works with single and three

RC-120S Remcon Relay Switch

Features:
• Switches AC power ON and OFF using low voltage
control circuit	• Built in transformer, no step down
transformers necessary		• Single relay can be controlled			REMCON SOLID STATE
by multiple switches		and	multiple relays can be		AMPROBE
				THIS DEVICE GENERATES HEAT
controlled by a single switch			• AC voltage from 105V ~	LOAD HOT	CAT . NO: RC - 120 S	UL
					NEUT.
				READ INSTALLATION INSTRUCTIONS!
125V • AC current up to 6.5A
705-1032-ND	(RC-120S). . . . . . . . . . . . . . . . . . . . . . $42.24

AT-1000 Advanced Tracer

Features:

• Trace energized lines up to 300VAC or VDC • Trace unenergized and open conductors • Identifies breakers and fuses without powering down • Locates shorts • Identifies wires in a bundle

• Identifies control, alarm and telephone system wiring • Traces coaxial cable shield • Receiver range 1 to 3 feet from a cable being traced

phase systems • Detects and records voltage anomalies, sags and surges • Built in scope displays waveforms • Phase sequence indication

•Records up to 64 parameters simultaneously

•Manual and programmable recording start • Line

or battery powered • Megohmmeter functions: test insulation of wires, cables,

transformers and electrical motors • Safety ratings: CAT III 600V phase to phase, CAT III 300V phase to ground

Includes: • CTs • Voltage leads • Ground probes and leads • PC software and download cable

705-1026-ND(DM-III MULTITEST F) . . . . . . . . . . . . . . . . . . . . . . . . . . $3484.20

PRM-3 Phase Sequence and Motor Rotation Tester

Features:

•Use for phase sequence testing, three phase motor

installation and maintenance

• Checks motors for rotation

direction • Identifies the

phase sequence of the three

phase electrical system

• Indicates normal or

reversed phases as well as

A B C

V

AMPROBE

PRM-3

Phase Sequence & Motor

Rotation Tester

Includes:

•Receiver • Transmitter • Carrying case • 110V pigtail cordset • Alligator clip cordset (2 pcs.) • CT-326 type adaptor

705-1018-ND(AT-1000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $370.04

AT-3000 PRO Underground Hawk Buried Wire and Pipes Tracer

Features:

• Locates underground energized

and de-energized wires, cables and

DM-4 Power Quality Recorder

Features:

loss of the phase

705-1031-ND(PRM-3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $105.69

pipes	• Depth measurement up to 10
feet	• Visual (LCD) and audible (with
loudspeaker) indicators • Rugged

AMPROBE

R-3000 PRO

•True RMS (TRMS) • Works with single (two and three wire) and three phase systems (Y and Delta)

•Detects and records voltage spikes 100nS or slower

•Detects and records voltage sags and surges • Built in scope displays waveforms • Records all parameters simultaneously • Manual and programmable recording start • Safety rating: CAT III 600V

Includes:

• Carrying case	• CTs • Test leads • PC software and
download cable	• Remote User Interface (PDA) with

12V		RS232	-E
		Spike
		IR
	AMPROBE
	DM-4 Power Quality Recorder
ON/OFF LED		STATE	RECORD LED
Unit-ON-AC Power		Green Solid
Unit-ON-Battery Power		Red Solid	Record
Low Battery		Slow Blink	Low Memory
	MAX 1V~
ON/OFF	I1	I2	I3
RECORD
	! CAT III 600V/CAT II 1000V
COM	V1	V2	V3

GP-2 Ground Resistance and Resistivity Tester

Features:

• Measure earth ground resistance; 3 point or 2 point
tests	• Automatically calculates resistivity;	4 point
test	• Automatic voltage measurement prevents false
measurements • Automatically applies three testing
frequencies for the most accurate readings		• Auto

GP - 2 GeoTest

AVG DIST

DISP GO

durable construction • Backlight

• Real Sound Technology - the sound

is derived from the signal radiating

from the cable or pipe • Ready for use

with receiver, transmitter, connection

cable, ground stake and ground

cable • Allows user to pinpoint the

path of the underground traced object

• Weatherproof and drop resistant

G-3000 PRO

R-3000 PRO

protective hard case and interface cable

705-1024-ND(DM-4) . . . . . . . . . . . . . . . . $3695.68

ranging	• 999 internal memory locations to store
measurements • RS-232 download to a personal
computer	• Safety rating: CAT III 250V

CLR ESC

RCL SAVE

705-1019-ND(AT-3000 PRO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $2638.26

DGC-1000A Clamp-on Ground Resistance Tester

Features:

•Accurate ground resistance measurement from 0.025Ω ~ 1500Ω • TRMS current measurement

•Continuity beep if the resistance is lower than 40.00Ω

•Data logging capability: 116 records • Individual data point recording • User selectable high and low Ω audible alarms • Auto power off • Low battery indicator • Large LCD display • Safety rating: CAT III 300V, CAT II 600V

HOLD

OFF

FUNC REC

Includes:

• Test leads • Auxiliary electrodes • Software • Carrying Case

705-1027-ND(GP-2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $1585.07

Megohmmeters

AMB-25

Features:

• Test insulation of wires, cables, transformers and	MEM
	RE AD
	MK
motors • Comes as a complete kit including test	VG
leads • Internal memory

Specifications:

TIF300HV Tic Tracer -

AC Voltage Detector

Features:

• Use to check fuses, break panels, power outlets, transmission lines, etc.

• Safety rating: UL, CE and MSHA Approved

705-1035-ND(TIF300HV). . . . . . . . . . . . . . . . $73.97

705-1036-ND48” Hot Stick (TIF410A). . $105.69

705-1023-ND(DGC-1000A) . . . . . . . . . $1479.33

• Insulation resistance with 250, 500 and 1000 VDC test voltages: 0 ~ 4.000 / 40.00 / 400.00 / 4000MΩ

BT-250Break’r Trac’r™

TMULD-300 Leak

Detector Kit

Features: • Locates arcing in an electrical system • Transmitter “pressurizes” area with ultrasonic sound enabling the ULD- 300 to pinpoint leaks • Applications include air tightness of cars or houses • Useful in finding the ends of buried PVC pipes

•Detects any pressurized gas leak regardless of type CFC’s, HFC’s, Nitrogen, etc.

Includes: • Ultrasonic transmitter • Flexible tubing adapter • Tubular extension • Parabola

• Headphones

		10
		8
		6
		4
HIGH
LOW		2
X1	RANGE	O
X10		I
X100

BATTERY

ULTRASONIC

LEAK DETECTOR

Model

ULD-300

8

7 6

POWER

HIGH

MED MODE

LOW

OFF

ON

ULTRASONIC TRANSMITTER MODEL UT-300

•Resistance: 0 ~ 9999Ω

AMB-45

Features:

MegaTest 1

•Test insulation of wires, cables, transformers and electrical motors • Comes as a complete kit including test leads and PC software • Pro- grammable timer • Internal memory • Safety rating: CAT III 600V

Specifications:

•Insulation resistance with 250, 500 and 1000 VDC test voltages: 0 ~ 4.000 / 40.00 / 400.00 / 4000MΩ

•Resistance: 4000Ω • AC/DC Voltage: 600.0V

Features:

•Identifies circuit breaker location

•Works on all electrical systems from

90 to 250 VAC • Automatic sensitivity

adjustment	• Quick and easy to use			ON
• Extremely	accurate	reading always		ADJUSTMENT
				AUTO
				SENSITIVITY
finds the right breaker		• Safety rating:	BT-250T	Break’r
UL approved			Use on 90-2250VAC
			Transmitter for	OFF
			Break’r Trac’r
			25/ 50/60 Hz Circuits	Trac’r
Includes:				BT-250R
• Transmitter	• Carrying case • Test leads			AC circuit
				breaker identifier
• Socket adapter
705-1022-ND	(BT-250) . . . . . . . . $105.69			Made in the USA

705-1037-ND(TMULD-300) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $422.92

TH-2A Digital

Thermo Hygrometer

AMC-2

Features:

•Test insulation of wires, cables, transformers and electrical motors • Does not require batteries or any external power supply, always ready for use • Ohmmeter

MODEL

AMC-3

OHMS		5. 2.0	0
	1	0
	2		50
		100	200 0
	5
20	0

MEG-OHMS

AT-4004/AT4005 Advanced Wire Tracers	K
AT-4005CON
CAT III 600V MAX
MODE SENSITIVITY
SIGNAL LEVEL

Features:
• Temperature readings
• Relative humidity measurement		MX/MN	HOLD
• Max/Min with time stamp		%RH	°C/°F
• Data hold function		TEMP
• Selectable °C and °F readout
• Dual LCD display with bargraph indication		AMPROBE
• Auto power off		TH-2Ai
		Thermo
		Digital
		Hygrometer
705-1033-ND	(TH-2A) . . . . . . . . . . . . . . $84.54

THWD-2 Digital Sling

Psychrometer

Features:

• Temperature readings

• Relative humidity measurement

• Dew point and wet bulb readings	MX/MN HOLD
	MEM °C/°F
• Max/Min with time stamp		READ
	%RH	DEW
• Selectable °C and °F readout	TEMP	WET
• Data hold function
• Dual LCD display with bar graph indication	AMPROBE
	THWD-2i
• Auto power off	Digital
	Psychrometer
	Sling

705-1034-ND(THWD-2). . . . . . . . . . . . . . $116.26

Specifications:

• 500VDC Test Voltage: 0 ~ 100MΩ ±5% Rdg	MEG-OHM
	OHM

@ (0.1 ~ 50MΩ) ±10% Rdg @ > 50MΩ

AMB-5KV-D

Features:

• Test insulation of wires, cables, transformers, electrical motors and generators • Comes as a complete kit including test leads and PC software

• Built in automatic voltmeter up to 5000V warns against hazardous energized systems • Programmable setups of test voltages and timers

Specifications:

•Voltages: 100V ~ 5000V • Resistance: 100kΩ ~ 500GΩ • Voltmeter: 0 ~ 5000V ± (10% Rdg = 10 LSD) @ 0 ~ 500V ± (10% Rdg + 5 LSD) @ 500V ~ 5000V • Memory: 20 programmable setup configurations

705-1014-ND(AMB-25) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $317.17

705-1015-ND(AMB-45) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $475.79

705-1017-ND(AMC-2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $687.27

705-1016-ND(AMB-5KV-D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $2379.14

ON/OFF	ON/OFF
AMPROBE
	SIGNAL LEVEL
TRANSMITTER	CON
	RECEIVER
T-4000	R-4000
AMPROBE	AMPROBE

Features:

•One universal transmitter; automatically switches to work with either energized or non-energized systems • Receiver not position sensitive

•Traces live wires buried or hidden behind walls • Locates breakers, neutrals and ground lines • Pinpoints shorts, ground faults and broken wires

•Clamp-on attachment injects signal for non-contact operation • Safety rating: CAT III 600V

Includes:

•Hard carrying case • Receiver • Transmitter • 110V pigtail - banana plug cord set • Alligator clip - banana plug cord set • Grounding test lead, 25 ft. with alligator clip • Clamp-on transmitter accessory • Rechargeable battery pack and battery pack recharger (AT4005CON Only)

705-1020-ND(AT-4004CON) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $793.01

705-1021-ND(AT-4005CON) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . $951.63

All prices in Canadian dollars and include duty and brokerage fees.
