JL Audio SB-GM-TRLBLZR/10W3v3/DG, SB-GM-TRLBLZR/10W3v3/GA, SB-GM-TRLBLZR/10W3v3/TN warranty E P

SB-GM-TRLBLZR/10W3v3_INSTR_SKU#011184

I N S T A L L A T I O N G U I D E

for the

SB-GM-TRLBLZR/10W3v3

2002-Up Chevrolet Trailblazer

2002-Up GMC Envoy

2003-Up Buick Rainier

If you choose to perform the installation yourself, it is absolutely vital that the Stealthbox® be properly mounted to the vehicle according to these instructions. Failure to mount the enclosure properly presents two problems:

1)The sub-bass performance will suffer due to the movement of the enclosure caused by the force exerted by the woofer(s).

2)A loose enclosure presents a serious safety hazard in the event of a collision or sudden deceleration.

INSTALLATION D I F F I C U LT Y :

2OUT

5OF

Thank you for choosing a JL Audio Stealthbox® for your automotive sound system. With proper

installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.

We strongly recommend that you have your new Stealthbox® installed by your authorized JL Audio dealer. The installation professionals employed by your dealer have the necessary tools and experience to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage extends to 2 years if your system is installed or approved by your authorized JL Audio dealer. If you prefer to perform your own installation, please read this installation guide completely

before beginning the process.

S T E P 1

Remove all contents from the cargo area.

S T E P 2

With a 7mm socket, remove the two bolts that are located at the rear of the passenger's side rear wheel well.

S T E P 3

With a flat bald screw driver, remove the two push/pull tabs that are located behind the passenger's side rear tire.

Continued on Next Page
