LCD Monitor/Viewfinder Indications

During Video Recording Only

aSelected Wipe/Fader Effect Indicator (墌pg.30)
bTape Running Indicator (墌pg.11)
(Rotates while tape is running.)
cSelected Wide Mode Indicator (墌pg.26)
dRecording Speed Mode (SP/LP) (墌pg. 26)
eTape Remaining Time (墌pg.12)
fREC: (Appears during recording.) (墌pg. 11)
PAUSE: (Appears during Record-Standby mode.)
(墌pg.11)
gInsert Editing/Insert Editing Pause Mode (墌pg. 37)
hWind Cut Indicator (墌pg. 27)
iSound Mode Indicator (墌pg.26)
(Appears for approx. 5 seconds after turning on the
camcorder.)
jTime Code (墌pg.27, 28)
kDigital Image Stabilizer (“DIS”) (墌pg.26)

During D.S.C. Recording Only

aImage Size: 1024 (1024x 768) or 640 (640 x 480)
(墌pg.28)
bShooting Icon (墌pg.18)
(Appears and blinks during shooting.)
cCard Icon (墌pg.18)
: Appears during shooting.
: Blinks in white when a memory card is not loaded.
dPicture Quality: (FINE) and (STANDARD) (in
order of quality) (墌pg.27)
eRemaining Number Of Shot (墌pg.18 )
(Displays the approximate remaining number of shots
that can be stored during D.S.C. recording. The
number increases or decreases depending on the
Picture Quality/Image Size, etc.)

During Both Video And D.S.C. Recording

aOperation Mode (墌pg.8)
b: Night-Alive Indicator (墌pg.29)
(Appears when Night-Alive is engaged.)
:Gain Up Mode (墌pg. 26)
(Appears when “GAIN UP” is set to “AUTO” and the
shutter speed is automatically adjusted.)
cWhite LED Light Indicator (墌pg.29)
dWhite Balance Indicator (墌pg.33)
e:Backlight Compensation Indicator (墌pg. 33)
±:Exposure Adjustme nt Indicator (墌pg. 32)
fSelected Program AE With Special Effects Indicator
(墌pg.30)
gIris Lock Indicator (墌pg.32)
hApproximate Zoom Ratio (墌pg.12)
(Appears during zooming.)
iZoom Indicator (墌pg.12)
(Appears during zooming.)
(The level indicator g moves.)
jO: (Appears when taking Snapshot.) (墌pg. 31)
kBRIGHT: Brightness Control Indicator (LCD monitor/
Viewfinder) (墌pg.9)
(The level indicator g moves.)
lBattery Indicator (墌pg. 43)
mDate/Time (墌pg. 8)
nManual Focus Adjustment Indicator (墌pg. 32)
SOUND
12
bit
1h40m
15:55
REC
51
1024
O
3
40
x
W
T
N
O
1
V
0
1
0
0
0
'
0
A
4
M
:
BRIGHT
g

1

2

3

4

5

6

7

89

0

q

w

g

er
